Aegis HDMI-SD-MP1010 HDMI & Analog Interface Board for Tamron MP1010M-VC Camera Module
*In Stock Now Only 5 Left, Call For Replacement Options
The Aegis HDMI-SD-MP1010 Interface Board provides HDMI and analog video output for the Tamron MP1010M-VC Full HD zoom camera module. Designed for seamless integration, this compact board converts the camera’s digital output into HDMI and NTSC/PAL analog video formats while enabling VISCA serial control and GPIO zoom/focus operation.
Ideal for machine vision, robotics, surveillance systems, and OEM camera integrations requiring HDMI monitoring or legacy analog video compatibility.
The Aegis HDMI-SD-MP1010 Interface Board is designed specifically to provide HDMI and analog video output for the Tamron MP1010M-VC Full HD camera block. This compact interface solution allows system integrators and OEM developers to easily convert the MP1010M-VC camera module output into HDMI or standard definition analog video formats.
Supporting HDMI 1.3 digital output and VBS/Y-C analog video formats, the HDMI-SD-MP1010 enables flexible video integration into modern displays, capture systems, and legacy monitoring equipment. The board also supports NTSC and PAL video standards, with selectable letterbox or crop conversion modes for optimized video scaling.
For camera control, the board provides TTL-level VISCA serial communication along with GPIO inputs for zoom, focus, and freeze functions, enabling seamless integration with embedded control systems, robotics platforms, and surveillance solutions.
Its compact footprint of 52 mm x 41.4 mm makes the HDMISDMP1010 ideal for embedded vision systems, compact imaging devices, and custom camera assemblies.
Features:
- HDMI output
- VBS & YC analog video output
- NTSC / PAL video format
- “letter box” / “Crop” analog video conversion
- 720p50/60, 1080p25/30, 1080p50/60
- TTL - VISCA serial control
- GPIO’s for zoom, focus, freeze control
- 8 to 12 VDC Power supply
- Size : 52 mm x 41.4 mm
Applications
- Machine Vision
- Robotics
- Surveillance
- Inspection
- UAV Imaging
- Industrial Cameras
- Security Systems
- OEM Imaging Devices
| Digital Video Output | HDMI 1.3 |
| Analog Video Output | VBS & Y/C NTSC/PAL format |
| Analog Video Conversion | « Letter box » or « Crop » format |
| GPIO Control | Zoom, focus, freeze |
| Camera Control | VISCA - TTL level |
| Power Supply | 8 to 12 VDC, 5 W (including camera) |
| Operating Temperature Range | 0°C to 60°C |
| Storage Temperature Range | -20°C to 60°C |
| Regulation | EMC FCC part 15, PCB : UL 94 V0 |
| Dimensions (mm) | 52 (H) x 41.4 (W) |
