MP3010M-EV 10x Zoom Camera with Sony STARVIS™ Sensor and up to 1080P60 Output
Engineered as a replacement for its predecessors, the NDAA compliant MP3010M-EV enhances imaging performance with advanced Electronic Image Stabilization (EIS), delivering smooth, stable video output by compensating for vibrations and shakes in high-frequency environments.
With a compact footprint of only 59 mm in length and a weight of just 70g, this camera houses a high-performance 10x optical zoom (f=3.3–33mm, F/1.8–3.4), enabling seamless transitions from wide-angle views to detailed telephoto shots, making it ideal for tight installation spaces.
The MP3010M-EV supports 1080P60 Full HD output, ensuring high-resolution video capture for a range of applications. Its Sony STARVIS™ CMOS sensor enhances low-light performance with a minimum illumination of 0.1 lx (color) and 0.025 lx (B&W), while the Day/Night function automatically switches between imaging modes for optimal performance in varying light conditions.
Connectivity is robust, featuring LVDS, HDMI, and UVC video outputs (up to 1080/30p UVC), accommodating all HD formats up to 1080/60p. Control is facilitated through VISCA™ protocol via TTL/RS-232/RS-485 serial communication, allowing for precise camera adjustments and integration into automated systems.
Designed for demanding applications such as industrial automation, robotics, surveillance, video conferencing, and transportation systems, the Tamron MP3010M-EV sets a new benchmark in compact, high-performance camera modules, combining advanced imaging technology with ease of integration and superior functionality.
Features:
- Compatible design with previous models MP1010/MP1110 series
- High Sensitivity (utilize Sony STARVIS™ High sensitivity image sensor )
- Day/Night function (ICR) for outdoor surveillance
- LVDS/HDMI and CVBS video output
- Supports all HD modes up to 1080/60p.
- Enhanced EIS (Electric Image Stabilizer)
- Use of VISCA™ protocol TTL/RS-232/RS-485 serial for camera control
- 10x optical zoom
- 70g
Applications:
- Industrial Automation
- Robotics
- Surveillance
- Video Conferencing
- Transportation Systems
| Image Sensor | Sony's CMOS image sensor with STARVIS™ technology |
| Pixel Output (HxV) | 1920x1080 or 1280x720 |
| Signal system HD | 1080p/60, 1080p/59.94 1080p/50,1080p/30, 1080p/29.97,1080p/25, 720p/60, 720p/59.94, 720p/50, 720p/30, 720p/29.97, 720p/25 (interlace not supported) |
| Signal system SD | NTSC/PAL |
| Minimum Illumination | 0.1 lx (1/30sec,F/1.8,50%,Color,Typical ) 0.025 lx (1/30sec,F/1.8,50%,B&W,Typical ) |
| S/N | More than 50dB |
| Gain | Auto/Manual |
| Shutter Speed | 1/1～1/10,000 sec |
| Exposure Compensation | -12dB 〜 +12dB ( Total 13 steps ) |
| Backlight Compensation | OFF/ON |
| Gamma | standard/straight/narrow/wide |
| Aperture Control | 16 steps |
| White Balance | ATW1(Narrow), ATW2(Wide), INDOOR, OUTDOOR, One push, Manual |
| AE (Auto exposure mode) | Auto, Manual, Priority mode (shutter/iris) |
| Lens (wide〜tele) | 10x optical zoom f=3.3～33mm F/1.8～3.4 |
| Zoom Mode | Standard/Variable/Direct |
| Zoom movement speed (wide to tele) | 1.7 sec (Focus Tracking ON) |
| Digital Zoom | Up to 16x |
| Focus | Auto/Manual/One-push, AF sensitivity |
| Minimum Object Distance (MOD) | Visible light: 10mm(wide)～800mm(tele) 850nm: 10mm(wide)～1200mm(tele) |
| Horizontal Viewing Angle | 59.2°(w)～6.7°(t) ※ except when EIS is operated) |
| Day/Night | ON/OFF (ICR switching) |
| Horizontal Resolution | Center : 800TV lines (Typical) |
| Video Output HD | LVDS: digital Y/Pb/Pr 4:2:2 HDMI*3: digital Y/Pb/Pr 4:2:2 (HDMI Type D) |
| Video Output SD | CVBS 1.0V(p-p,75Ω) |
| EIS (Electronic Image Stabilization) | OFF/ON |
| Picture Effects (Black White) | OFF/ON |
| Wide-dynamic Range (Gamma) | OFF/ON |
| Picture Freeze | OFF/ON |
| Day/Night (ICR) | OFF/ON/AUTO |
| Electronic Flip (E-Flip) | OFF/ON |
| Defog | OFF/ON (Level : 1〜3) |
| Noise Reduction (3D + 2D) | OFF/ON (Level : 1〜5) |
| Temperature Readout | available |
| Privacy Zone Mask | Up to 8 places |
| Title Display | OFF/ON (20 characters/line, max. 12 lines) |
| Slow Shutter | OFF/ON (Max 1sec) |
| Power Requirements | DC 8～12±10% |
| Power Consumption | Approx.2.5W (Approx 4.4W in the zoom and focus operation) |
| Operating Temperature | -5℃～+60℃ |
| Recommended Temperature | 0〜+40°C |
| Operating Humidity | 30%〜80% (no condensation) |
| Storage Temperature | -40〜+60°C |
| Dimensions (W x H x D) | 33 x 43 x 59 mm |
| Weight | Approx.70g |
