KT&C ATC-HZ5530Z-LPN (ATCHZ5530ZLPN) HD 1.58MP Auto Focus 25x Optical Zoom Block Camera

The KT&C ATC-HZ5530Z-LPN is a high-performance surveillance camera engineered for superior imaging and flexible deployment in diverse environments. Utilizing a 1/2.9" Progressive Scan Global Shutter CMOS sensor, this camera delivers exceptional image quality with an effective pixel count of 1.58MP (1456 x 1088). The robust 300x AF Zoom feature, comprising a 25x optical and a 12x digital zoom, enables precise long-distance monitoring.

With a maximum video resolution of 720p at frame rates of 60, 50, 30, and 25 fps, this camera excels in dynamic settings, ensuring clear footage. The mechanical Day & Night function, alongside True Wide Dynamic Range (WDR), guarantees optimal performance in varied lighting conditions, while 3D Digital Noise Reduction (DNR) and Defog capabilities enhance image clarity.

This NDAA compliant camera supports multiple control protocols including Pelco-D, VISCA, and Hitachi via UART RS232-TTL, making it compatible with various control systems. Key features include 256 position presets, adjustable white balance modes, and advanced motion detection across four zones. Built for resilience, it operates within a temperature range of -10℃ to +50℃ and has a compact design measuring 50.0 x 58.8 x 96.1 mm, weighing approximately 240g. With power consumption capped at 5.3W, it ensures efficient operation without compromising performance.

Features:

• 1/2.9 Progressive Scan Global Shutter CMOS
• 300x AF Zoom(25x optical zoom, 12x digital zoom)
• 720p 60/50/30/25fps
• Mechanical Day&Night
• True WDR
• 3D DNR, Defog
• Global Shutter, Trigger In&Strobe Out
• UART RS232-TTL(Pleco-D, Pelco C, VISCA, Hitachi)

Applications:

• Surveillance and Security Systems
• Traffic Monitoring
• Public Safety and Law Enforcement
• Industrial Automation
• Remote Site Monitoring
• Event Security
• Wildlife Observation
