Tru-Vu SRMHOBTPWP-15C (SRHMOBTPWP15C) 15” Sunlight Readable Waterproof Panel-Mount Touch Screen Monitor
*Product is discontinued, Replacement Option: SRMHETRWP-15C
The SRMHTWP-15 Series Sunlight Readable waterproof panel-mount touch screen monitors are designed to operate in direct bright sunlight or in other high ambient-light conditions. They utilize state-of-the-art LED backlights to produce over 1,500 nits of brightness (vs. 250-300 nits for standard monitors).
All TRU-Vu industrial LCD monitors are specifically designed for use in demanding applications. Every TRU-Vu monitor utilizes industrial-grade components and high-end LCD panels not found in retail/consumer-grade monitors. This ensures superior image quality, improved performance and greater durability. Our 3-Year Warranty ensures you of reliable worry-free operation.
Features:
Applications:
| Model | SRMHOBTPWP-15C |
| LCD Panel | 15” Color TN LCD Panel (LED Backlights) |
| Touch Technology | Projected Capacitive (P-Cap) |
| Touch Interface | USB |
| Resolution | 1024 x 768 (XGA) |
| Viewable Area | 11.97” (W) x 8.98” (H) (304.12 x 228.09 mm) |
| Pixel Pitch | 0.297mm |
| Display Colors | 16.2 M |
| Aspect Ratio | 4:3 |
| Brightness | 1,500 nits |
| Contrast Ratio | 700:1 |
| Optical Bonding | Standard |
| Response Time | 8 msec Trf |
| Viewing Angle | 170° (H) x 160° (W) |
| Control | OSD (On-Screen Display) via Rear Panel Pushbuttons |
| Video Inputs | VGA & DVI |
| Power Requirement | 90-240 VAC |
| Power Consumption | 48 Watts |
| Enclosure | Stainless Steel Panel-Mount (Rear Clamp) |
| Rating | NEMA 4X / IP65 |
| Operating Temperature | 32˚ to 149˚F (0 to 65˚C) |
| Humidity | 8-90%RH |
| Shock | 50 G (20 msec, ½ sine) |
| Vibration | 1.5G RMS 10-200 HZ |
| Dimensions | 15.98” (W) x 12.39” (H) (405.80 x 314.60 mm) |
| Warranty | 3 Years |
