Canon Medical Systems IK-HD3H (IKHD3H) HD 3CMOS HD DVI-i Remote Head Camera
SKU
IK-HD3H
Quick Overview
1920 x 1080, 2.1 MP 1/3" PS CMOS, Ultra Small True HD DVI-i Remote Head Camera.Can be used with:IK-HD3D
The IK-HD3H is Canon Medical's most advanced 3-chip HD video camera. It provides unprecedented user-controlled features and advanced noise reduction technology. This feature-rich progressive scan, 1080p, 2.1MP, HD CMOS camera is based on Canon Medical's state-of-the-art prism block technology to produce optimal color accuracy, high resolution, and increased sensitivity from an extremely compact package. The IK-HD3H remote-head camera is ideal for 3D imaging, microscopy, scientific imaging, diagnostics, aerospace/aviation, specialty broadcast, and other applications where exceptional video performance and increased sensitivity is required, and space is limited.
Features:
- 2.1MP, progressive, 1/3" HD CMOS sensors
- 1920 x 1080 Digital DVI output
- High sensitivity and wide dynamic range
- Up to 1,000 TV lines resolution (IK-HD3H)
- 5 User-configurable scene files to achieve exceptional color accuracy and control
- Binning mode for 4x increase in sensitivity
- Image flip and mirror
- Switchable between 1080p and 1080i
- Gen lock for 3D and multi-camera use
- IK-HD3H and IK-HR3H Camera heads are interchangeable with controller
- Remote control via RS232
- C-mount lens mount
Applications:
- 3D Imaging
- Microscopy
- Scientific Imaging
- Diagnostics
- Aerospace/Aviation
- Broadcast
| Image Sensor | 3 CMOS, 1/3 inch, 2MP progressive |
| Output Resolution | Horizontal: 1920, Vertical: 1080 |
| Resolution | H: 1000 TV lines standard V: 1000 TV lines standard |
| Sensitivity | F10 standard (59.94 Hz setting) F11 standard (50 Hz setting) (at 2000 lx, 3000 K) |
| Minimum Illumination | 4.8 lx (59.94 Hz setting) 4.0 lx (50 Hz setting) at F2.2, 20 dB, BINNING: OFF 9.6 lx (59.94 Hz setting) 8.0 lx (50 Hz setting) at F2.2, 20 dB, BINNING: OFF |
| S/N Ratio | 56 dB standard AGC: OFF, Gamma: OFF, Enhance: OFF |
| Ambient Temperature | 0°C to 40°C / 32°F to 104°F |
| Ambient Humidity | Less thank 90% |
| Weight | Approx. 93 g (3.3 oz) |
| Dimensions | W: 32.6 mm H: 38.6 mm D: 41 mm (1.28" x 1.52" x 1.61") |
