Wonwoo MC-S189Q 4MP HD 18x Zoom Block Camera Module with 6 MP Sony CMOS sensor
The Wonwoo MC-S189Q is a NDAA compliant, high-performance 4MP 18x optical zoom camera module designed for exceptional video clarity and versatility in various surveillance and imaging applications. Featuring a 1/1.8" 6MP Sony CMOS sensor, it supports resolutions up to 1440p at 30fps, with additional settings for 1080p and 720p at 30fps. Its 18x optical zoom (6.8mm ~ 122.4mm), paired with 32x digital zoom, offers extensive flexibility for detailed imaging across various environments.
Key features include Wide Dynamic Range (WDR) for improved image detail in challenging lighting conditions, Digital Noise Reduction (2D+3D) for cleaner video, and Day & Night (ICR) functionality for optimal performance in both bright and low-light settings. The F1.61 (wide) ~ F4.13 (tele) aperture range further enhances image quality across the zoom spectrum.
This module also integrates Digital Image Stabilization for smoother video in dynamic conditions and offers advanced features like Intelligent Motion Detection, High Light Compensation, and Defog Function for enhanced clarity in challenging scenarios. The Privacy Mask Function ensures secure operation, while the device supports popular protocols such as VISCA, Pelco-D/P, and offers multiple video outputs including LVDS, EX-SDI, and CVBS for versatile connectivity options.
Features:
- 1/1.8" 6MP Sony CMOS Sensor
- 1440p 30fps, 1080p 30fps, 720p 30fps
- 18x Optical Zoom (6.8mm ~ 122.4mm) & 32x Digital Zoom
- F1.61(wide) ~ F4.13(tele)
- Day & Night(ICR)
- Wide Dynamic Range
- Digital Noise Reduction(2D+3D)
- Digital Image Stabilization
- Privacy Mask Function
- High Light Compensation
- Intelligent Motion Detection
- Defog Function
- Supports VISCA, Pelco-D/P Protocol
- Video Out: LVDS, EX-SDI, CVBS
Applications:
- Surveillance Cameras
- Security Systems
- Remote Monitoring
- License Plate Recognition
- Smart City Monitoring
- Industrial Inspection
- Traffic Surveillance
- Retail Analytics
- Border Security
- Automated Cameras
| Image Sensor | 1/1.8" Sony CMOS Image Sensor |
| Total Pixels | 3,096(H) x 2,094(V) = 6.48M Pixels |
| Active Pixels | 3,089(H) x 1,744(V) = 5.39M Pixels |
| Scanning System | Progressive Scan |
| Sync. System | Internal |
| Resolution | 1440p30(25)fps, 1080p30(25)fps, 720p30(25)fps |
| Min. Illumination | Color: 0.2 lux, BW: 0.06lux |
| Video Output | Digital: LVDS, EX-SDI; Analog: CVBS |
| Lens Type | 18x Day & Night Zoom Lens |
| Zoom Ratio | Optical 18x, Digital 32x Zoom |
| Focal Length | f = 6.8mm ~ 122.4mm |
| Aperture Ratio | F1.61 (wide) ~ F4.13 (tele) |
| Angle of View (D, H, V) | Wide: 54.4°, 48.3°, 28.3°; Tele: 3.4°, 2.9°, 1.6° |
| AF Mode | Auto / One Push / Manual |
| Min. Distance | 0.5 / 1.5 / 3.0 / 5.0 / 10.0 m |
| Shutter | Auto / Manual: 1/1 ~ 1/10000 sec |
| White Balance | Auto / ATW / Indoor / Outdoor |
| WDR | 120 dB |
| Backlight Compensation | Yes |
| Digital Slow Shutter | Yes |
| Privacy Mask | Yes |
| Motion Detection | Yes |
| Defect Detection | Yes |
| Power Supply | DC 9V ~ 15V |
| Control Protocol | Pelco-P, Pelco-D, VISCA |
| Power Consumption | Max. 5.5W |
| Storage Temperature | -20℃ ~ +60℃ (Humidity : 0%RH ~ 90%RH) |
| Operating Temperature | -10°C ~ 50°C |
| Dimensions | 50(W) x 62(H) x 97.9(D) |
| Weight | 288g |
