VS Technology VSZ-0745-MR Motorized Zoom Lens
Enhanced Imaging Precision with VS Technology VSZ-0745-MR Motorized Zoom Lens
Immerse yourself in the cutting-edge world of industrial imaging with the VS Technology VSZ-0745-MR Motorized Zoom Lens. Engineered for excellence, this lens boasts a remarkable 1:6.5 zoom ratio, ensuring unparalleled versatility in capturing intricate details. The long working distance of 100mm enhances flexibility in imaging setups, providing a wide scope for applications in industrial and machine vision.
The lens features a ±3mm focus adjustment system, empowering users with precise control over imaging parameters. Its C-Mount design ensures compatibility with a range of industrial cameras, facilitating seamless integration into diverse setups. The motorized zoom capability elevates efficiency, allowing users to adapt focal lengths effortlessly.
Features:
- 1:6.5 Zoom Ratio
- Long 100mm Working Distance
- ±3mm Focus Adjustment
- C-Mount Compatibility
- Motorized Zoom Capability
Applications:
| Optical Mag. Range | 0.7x ~ 4.5x | ||
| Optical Mag. | x 0.7 | x 1.8 | x 4.5 |
| FOV (V x H) | 2/3" - 10.1 x 12.0 | 3.9 x 4.7 | 1.6 x 1.9 1/2" - 6.9 x 9.1 | 2.7 x 3.6 | 1.1 x 1.4 1/3" - 5.1 x 6.9 | 2.0 x 2.7 | 0.8 x 1.1 |
||
| WD | 100.0 mm ± 3 | ||
| O/I (Object & Imager distance) | 291.6 mm | ||
| Working F/# *Value at Iris open | 10.3, 13.8, 29.0 | ||
| NA | 0.034, 0.065, 0.078 | ||
| DOF at PCoC Ø 0.04mm2.5 | 1.7 mm, 0.3 mm, 0.1 mm | ||
| TV Distortion (1/1.8") | -0.03% | 0.09% | 0.08% |
| Wavelength | Visible | ||
| Mount | C-Mount | ||
| Flange Back | 17.526 mm | ||
| Sensor Size (max.) | 2/3" | ||
| Co-Axial Prism | - | ||
| Weight (approx.) | 590 g | ||
| Dimension | 54 x 93 (max.) x L = 174.1 mm | ||
