VS Technology VS-MC0576N Front Angled Group View

VS Technology VS-MC0576N Super Compact Macro Lens

VS Technology VS-MC1375-40N Super Compact Macro Lens

Discover precision in every detail with the VS-MC1375-40N Super Compact Macro Lens. Engineered for tight spaces, this lens by Aegis Electronic Group is your gateway to superior industrial imaging. Elevate your machine vision with the best in compact optics. Explore now!
SKU
VS-MC1375-40N

Revolutionize Precision Imaging with VS Technology's VS-MC1375-40N Super Compact Macro Lens

In the realm of industrial imaging, the VS Technology VS-MC1375-40N Super Compact Macro Lens stands out as a pinnacle of optical precision. Crafted by Aegis Electronic Group, this lens epitomizes innovation with its super compact design, making it an ideal choice for environments constrained by space.

Equipped with a versatile 1/6" support and an M12 P=0.5 mount, this lens offers unparalleled imaging capabilities in the realm of machine vision. Its smaller field of view (FOV) and long working distance (WD) make it a powerhouse for applications in confined spaces, ensuring optimal performance in situations where traditional lenses might fall short.

The VS-MC1375-40N lens is a beacon of excellence in compact imaging solutions, providing high-resolution macro imaging for industrial automation. Its micro optics technology ensures precision imaging, making it an indispensable tool for applications demanding intricate details and accuracy.


Features:

  • Super compact design
  • 1/6" support
  • M12 P=0.5 mount
  • Smaller FOV and long WD
  • Precision micro optics technology


Applications:

  • Industrial automation
  • Machine vision systems in confined spaces
  • High-resolution macro imaging
  • Optimal performance in small environments
Focal Length 35mm
Optical Mag. Range 0.85x ~ 1.375x
Optical Mag. x 0.85 x 1.0  x 1.375
FOV (V x H) 1/2"
1/3"
1/6" - 2.0 x 2.7 | 1.7 x 2.3 | 1.3 x 1.7
WD 43.5 mm 42.1 mm 39.8 mm
O/I (Object & Imager distance) 64.1 mm 64.0 mm 64.8 mm
Working F/# *Value at Iris open 7.4, 8.5, 11.0
NA 0.057, 0.059, 0.063
DOF at PCoC Ø 0.04mm 0.8 mm, 0.7 mm, 0.5 mm
TV Distortion (4/3") 0.53% 0.44% 0.30%
Wavelength Visible
Mount M 12 P= 0.5
Flange Back 9.89 mm
Sensor Size (max.) 1/6"
Image Circle Ø 3.7 mm
Weight (approx.) 2.5 g
Dimension Ø 14 (max.) x L = 10.7 (X0.85) ~ 15.1 (X1.375) mm
