VS Technology VS-MC0576N Super Compact Macro Lens
Unleashing Precision: VS Technology VS-MC0576N Super Compact Macro Lens
In the realm of industrial imaging, the VS Technology VS-MC0576N Super Compact Macro Lens stands as a testament to precision and innovation. Designed by the renowned Aegis Electronic Group, this lens caters to the unique demands of space-constrained environments. With a remarkable 1/6" support and an M12 P=0.5 mount, it excels in providing high-resolution imaging solutions for industrial and machine vision applications.
The VS-MC0576N's super compact model ensures optimal performance even in the smallest of spaces, making it an ideal choice for industries where real estate is a premium. Its smaller field of view (FOV) and long working distance (WD) further enhance its suitability for applications that demand meticulous attention to detail. This lens is a game-changer in quality inspection, micro-imaging, and various industrial automation processes.
Features:
- Super compact design
- 1/6" support
- M12 P=0.5 mount
- High-resolution imaging
- Ideal for small spaces
- Long working distance
Applications:
- Quality inspection
- Micro-imaging
- Industrial automation
- Precision optics
- Machine vision in confined spaces
| Optical Mag. Range | 0.365x ~ 0.85x | ||
| Optical Mag. | x 0.365 | x 0.576 | x 0.85 |
| FOV (V x H) | 1/2" - 1/3" - 1/6" - 4.7 x 6.3 | 3.0 x 4.0 | 2.0 x 2.7 |
||
| WD | 56.6 mm | 40.0 mm | 30.7 mm |
| O/I (Object & Imager distance) | 85.1 mm | 72.0 mm | 67.2 mm |
| Working F/# *Value at Iris open | 9.5, 11.0, 12.8 | ||
| NA | 0.019, 0.026, 0.033 | ||
| DOF at PCoC Ø 0.04mm | 5.7 mm, 2.7 mm, 1.4 mm | ||
| TV Distortion (1/6") | 0.019% | 0.00% | 0.00% |
| Wavelength | Visible | ||
| Mount | M 12 P= 0.5 | ||
| Flange Back | 9.89 mm | ||
| Sensor Size (max.) | 1/6" | ||
| Image Circle | Ø 3.7 mm | ||
| Weight (approx.) | 4 g | ||
| Dimension | Ø 14 (max.) x L = 18.6 (X0.365) ~ 26.6 (X0.85) mm | ||
