VS Technology VS-MC05-65 Fixed & Variable Magnification Macro Lens
Unleashing Precision: VS Technology VS-MC05-65 Macro Lens Excellence
Delve into the world of cutting-edge industrial imaging with the VS Technology VS-MC05-65 Macro Lens from Aegis Electronic Group. This lens boasts a versatile magnification range, supporting 0.1x to 2.0x fixed magnification and 0.24x to 1.0x variable magnification. With a Φ16 aperture and compatibility with 2/3" setups, this lens offers unparalleled clarity and precision in machine vision applications.
The VS-MC05-65 is not just a lens; it's a technological marvel. Its connectivity features ensure seamless integration into diverse imaging systems, providing professionals with a streamlined experience. The lens caters to a spectrum of industrial applications, from intricate inspections to quality control in manufacturing processes. Its 15 models with fixed magnification and 2 models with variable magnification offer tailored solutions for various imaging needs.
Features:
- Versatile 0.1x to 2.0x fixed magnification
- Variable magnification from 0.24x to 1.0x
- Φ16 aperture for high-resolution imaging
- 2/3" support for diverse setups
- Connectivity for seamless integration
Applications:
- Industrial inspections
- Quality control in manufacturing
- Precision imaging in automation
- Machine vision systems
- Macro vision solutions
| Focal Length | 27.5mm | ||
| Optical Mag. | x 0.5 ± 5 % | ||
| FOV (V x H) | 2/3" - 14.2 x 16.8 1/2" - 9.6 x 12.8 1/3" - 7.2 x 9.6 | ||
| WD | 69.1 mm ± 3 | ||
| O/I (Object & Imager distance) | 121.6 mm | ||
| Working F/# *Value at Iris open | 6.0 | ||
| NA | 0.042 | ||
| DOF at PCoC Ø 0.04mm | 1.9 mm | ||
| TV Distortion (2/3") | -0.02% | ||
| Relative Illuminance (Y=5.5) | 98 % | ||
| Wavelength | Visible | ||
| Mount | C-Mount | ||
| Flange Back | 17.526 mm | ||
| Sensor Size (max.) | 2/3" | ||
| Weight (approx.) | 17 g | ||
| Dimension | Ø 30 (max.) x L = 35 mm | ||
