VS Technology VS-0818H/3CMOS Megapixel Lens for 3CMOS Cameras
Unleash Precision Imaging with VS-0818H/3CMOS Megapixel Lens
Discover the pinnacle of imaging excellence with the VS0818H/3CMOS Megapixel Lens, an innovative solution from VS Technology proudly offered by Aegis Electronic Group. Purpose-built for multi-sensor 3CMOS cameras, these lenses redefine industrial imaging, providing unrivaled clarity and precision. Featuring comprehensive 1/1.8" sensor support, the lens series encompasses four distinct models, each with focal lengths of f8mm, f12mm, f16mm, and f25mm, ensuring adaptability across a spectrum of industrial applications.
The VS-0818H/3CMOS lens distinguishes itself through its commitment to high-resolution imaging, delivering exceptional visual fidelity in machine vision scenarios. Seamless connectivity enhances compatibility with 3CMOS cameras, facilitating an effortless integration process. The availability of four focal lengths empowers users with the flexibility to tailor their imaging setups to specific requirements, ensuring versatility in various industrial applications.
Features:
- Precision-crafted for multi-sensor 3CMOS cameras
- Four focal lengths: f8mm, f12mm, f16mm, f25mm
- 1/1.8" sensor support
- High-resolution imaging capabilities
- Seamless connectivity for efficient integration
Applications:
- Quality control and inspection
- Robotics and automation
- Semiconductor manufacturing
- PCB inspection
- Pharmaceutical production
- 3D measurement and profiling
| Focal Length | 8mm |
| Maximum Aperture Ratio | 1: 1.8 |
| Aperture | F 1.8 ~ Close |
| Angle Of View (1.1") | 36.6° x 47.3° (Diagonal: 57.9°) |
| M.O.D | 100 mm |
| TV Distortion (1.1") | -0.81 % |
| Operation | Manual (Lock screw M2) |
| Wavelength | Visible |
| Mount | C-Mount |
| Flange Back | 17.526 mm |
| Sensor Size (max.) | 1/1.8" |
| Filter Thread | M 30.5 P= 0.5 |
| Weight (approx.) | - |
| Dimension | Ø 35 (max.) x L = 57 mm |
