Vitek VTC-TNB8RMEA Transcendent 8MP Indoor/Outdoor WDR IP Motorized Turret Camera with Matrix IR's

SKU
VTC-TNB8RMEA
Quick Overview
The Vitek VTC-TNB8RMEA is an advanced 8MP IP turret camera designed for versatile indoor and outdoor use. With features like a motorized varifocal lens, Matrix IR night vision, and True Wide Dynamic Range, it delivers exceptional image quality and reliable performance in various lighting conditions. NDAA compliant and weather-resistant, this camera is perfect for comprehensive security coverage and remote monitoring.

Vitek VTC-TNB8RMEA: High-Performance 8MP IP Motorized Turret Camera

The Vitek VTC-TNB8RMEA Transcendent 8MP IP Motorized Turret Camera is engineered to deliver unparalleled security and surveillance capabilities for a variety of settings. Equipped with a 1/2.8” 8.0 MegaPixel CMOS image sensor, this camera provides stunning 4K resolution (3840 × 2160) at up to 20fps, ensuring clear and detailed footage. Its 2.8~12mm motorized varifocal lens allows for flexible focal length adjustments, while the Matrix IR technology offers night vision up to 165 feet, making it suitable for both indoor and outdoor environments.

The camera features True Wide Dynamic Range (120dB) and XD-DNR (3D & 2D-DNR) to handle challenging lighting conditions, ensuring clear images even in high-contrast or low-light scenarios. It supports multiple video compression formats including H.265+, H.265, and H.264, optimizing storage and bandwidth usage. The VTCTNB8RMEA is NDAA compliant, IP67 rated for weather resistance, and includes programmable analytics like intrusion detection and line crossing. With local storage capability of up to 256GB via microSD and compatibility with various remote viewing platforms, this camera is an ideal choice for high-definition surveillance across diverse applications.

Features:

  • 8MP Resolution: Provides 4K clarity (3840 × 2160) for high-definition surveillance.
  • 2.8~12mm Motorized Varifocal Lens: Allows flexible zoom and focus adjustments.
  • Matrix IR Technology: Night vision up to 165 feet for enhanced low-light performance.
  • True Wide Dynamic Range (120dB): Captures clear images in high-contrast environments.
  • XD-DNR (3D & 2D-DNR) Noise Reduction: Reduces image noise for sharper visuals.
  • NDAA Compliant: Meets National Defense Authorization Act standards for security equipment.
  • Local Storage: MicroSD slot supports up to 256GB for on-site recording.
  • Weather Resistance: IP67 rating ensures durability in harsh weather conditions.
  • Multiple Video Compression Formats: Supports H.265+, H.265, H.264+, and H.264 for efficient data management.
  • Programmable Analytics: Includes region intrusion, scene change detection, and line crossing capabilities.
  • Remote Viewing: Accessible via CMS, web browsers, and mobile apps (iOS/Android).

Applications:

  • Perimeter Security: Ideal for monitoring property boundaries and entry points.
  • Retail Surveillance: Useful for loss prevention and monitoring store activities.
  • Industrial Sites: Provides oversight in warehouses and manufacturing facilities.
  • Parking Lots: Ensures security and monitoring of vehicle movements.
  • Public Spaces: Enhances safety in areas like parks and plazas.
  • Residential Security: Protects home environments with high-resolution video and reliable night vision.
Image Sensor1/2.7” 8.0 Megapixel [4K] Progressive Scan CMOS
Image Size8 MegaPixel (3840 × 2160)
ResolutionUp to 20fps @ 8MP (3840 × 2160), 6MP (3072× 2048 ), 5MP (2592 ×1944 ), 720P (1280 × 720), D1, CIF, 480 × 240
Min. Illumination0.02 lux @ F1.6, AGC ON; 0 lux with IR, 0.01 lux @ F1.2, AGC ON; 0 lux with IR
Electronic Shutter1s ~ 1 / 100000s
Lens2.8~12mm Motorized Varifocal Lens
Day/NightTrue Day/Night by ICR
IR LEDs2 Matrix IRs
IR DistanceUp to 165‘
Video CompressionH.265+ / H.265 / H.264+ / H.264 / MJPEG
Audio CompressionG.711A / G.711U
Main Stream8MP [4K] (1~20fps) / 6MP / 5MP / 720P / D1 / CIF / 480 x 240 (1~30fps)
Sub Stream, Third Stream60Hz: 720P/D1/480 × 240(1~30fps), 60Hz: D1/CIF/480 × 240 (1~30fps)
Bit Rate / Type64 Kbps ~ 12 Mbps / VBR + CBR
WDR120dB Super WDR
DNR3D-DNR
Backlight CompensationYes
Highlight CompensationYes
DefogYes
Image SettingROI, Saturation, Brightness, Chroma, Contrast, Sharpen, NR; Adjustable through client software or browser
AnalyticsRegion intrusion, Scene Change Detection, Line Crossing, Video Blur, Video Color Cast Detection
Smart AlarmMotion Detection, SD Card Error, SD Card Full
General FunctionsWatermark, IP Filter, Video Mask, Illegal Login Lock
Region of Interest (ROI)Each ROI to be configured separately
Hardware ResetYes
Analog Video OutputNo
Audio1 Ch. Audio In + Built-in Mic*
Local StorageBuilt-in Micro SD card slot up to 256GB
Remote ViewingCMS / Web Browser / Mobile (iOS/Android)
Supported BrowsersInternet Explorer, Chrome and Firefox with IE Tab, and Edge in IE mode
Connection ProtocolONVIF
Weather ResistanceIP67 Weather Resistance
Power Input12VDC / PoE
Power Consumption (12VDC)350mA (IR Off) / 850mA (IR On)
Power Consumption (PoE)< 10W
Working Environment-4~140° / < 95% Humidity
Weight24.34oz / 1.52lb (690g)
Dimensions8.68 × 3.15 × 2.78” (220.5 × 80.1 × 70.5mm)
