Tru-Vu SRMOBWTR-10.4R (SRMOBWTR10.4R) Series 10.4” Waterproof Sunlight Readable Touch Screen

The SRMOBWTR-10.4R Sunlight Readable touch screen monitor is designed to operate in direct bright sunlight, or in other high ambient-light conditions. They utilize state-of-the-art LED backlights to produce over 1,000 nits of brightness (vs. 250-300 nits for standard monitors). This results in amazingly bright, crystal-clear images, even with direct, bright sunlight on the face of the screen. SRMOBWTR-10.4R Sunlight Readable touch screens will eliminate the need for sun-shields, squinting or straining to see washed-out images. The waterproof enclosure will prevent damage due to spray, saltwater, etc.
SKU
TruVu SRMOBWTR-10.4R Series 10.4” Waterproof Monitor

The SRMOBWTR-10.4R Sunlight Readable monitors are built with industrial-grade components and receive our exclusive TRU-Tuff treatment. The TRU-Tuff process includes RTV silicone on all connections and critical components; all wires are dressed, tie-wrapped and secured; and ThreadLock on all screws.



Features:



  • Produces Clear, Sharp Images Even in Direct, Bright Sunlight
  • 1,000 nits Brightness
  • Optical Bonding Improves Image Quality
  • 5-Wire Resistive Touch Screen
  • NEMA 4X Waterproof Stainless Steel Enclosure
  • TRU-Tuff Ensures Maximum Shock/Vibration Resistance
  • Lockable OSD (On-Screen Display) Controls
  • 3 Year Warranty
  •


    Applications:



  • industrial
  • military
  • law enforcement
  • aviation
  • marine
  • inspection
  • surveying,
  • cranes
  • oceanic
  • entertainment
  • transportation
  • Model SRMOBWTR-10.4R
    LCD Panel 10.4” LCD; LED Backlights
    Touch Technology 5-Wire Resistive Touch
    Touch Interface USB
    Resolution
    800 x 600 (SVGA)
    Viewable Area 8.3” (W) x 6.2 (H)   (211.2 x 158.4 mm)
    Pixel Pitch 0.264 mm
    Display Colors 16.2M
    Aspect Ratio 4:3
    Brightness 1,000 nits
    Contrast Ratio
    700:1
    Viewing Angle 160˚ (H) x 140˚ (V)
    Response Time 15 msec
    Control OSD (On-Screen Display) via Rear Panel Pushbuttons
    Video Inputs VGA, HDMI, DispayPort
    Power Requirement 12 VDC (2.1mm Barrel Plug);  90-240 VAC via Included Power Brick
    Power Consumption 13W (1.08A @ 12VDC)
    Operating Temp -31º to +185º F (-35º to +85ºC)
    Enclosure Stainless Steel Panel-Mount (Rear Clamp)
    Rating NEMA 4X / IP65
    Shock
    50G, 20ms, Half-sine wave
    Vibration 1.5G RMS 10-200 HZ 30 mins/axis (X,Y,Z)
    Warranty 3 years
