Tru-Vu SRMHTC-8.4C-24 (SRMHTC8.4C24) Sunlight Readable LCD Monitor
Tru-Vu's SRMHTC is Sunlight Readable LCD Touch Screen monitors designed for use in direct bright sunlight, or in other high ambient light conditions. The SRMT-8.4 Series Sunlight Readable LCD Touch Screen monitors are designed for use in direct bright sunlight, or in other high ambient-light conditions. They utilize state-of-the-art LED backlights to produce over 1,000 nits of brightness (vs. 250-300 nits for standard monitors). This results in amazingly bright, crystal-clear images, even with direct, bright sunlight on the face of the screen.
SKU
"SRMHTC-8.4C-24 -TruVu"
The SRMT-8.4 Series Sunlight Readable Touch Screen LCD monitor is built with industrial-grade components and receives our exclusive TRU-Tuff treatment. The TRU-Tuff process includes RTV silicone on all connections and critical components; all wires are dressed, tie-wrapped and secured; and ThreadLock on all screws.
Features:
Applications:
| LCD Panel | 8.4” Color LCD with LED Backlights |
|
Touch Screen Type
|
Surface Capacitive Touch
|
|
Touch Interface
|
USB |
| Resolution | 800 x 600 |
| Viewable Area | 6.70” x 5.03” |
| Pixel Pitch |
0.213 mm |
| Display Colors | 16.2m |
| Aspect Ratio | 4:3 |
| Brightness | 1,500 nit |
| Contrast Ratio | 700:1 |
| Viewing Angle | 160° x 140° |
| Response Time | 30 msec |
| Control | OSD |
| Video Inputs | VGA & DVI |
| Power Requirement | 12-24 VDC |
| Power Consumption | 11.2W |
| Mounting | 75 x 75 mm VESA Hole Pattern |
| Operating Temperature | -35°C to 85°C |
| Shock | 50G, 20ms, Half-sine wave |
| Vibration | 1.5C (10-200Hz, P-P) 30 mins. |
|
Dimensions
|
8.7” x 6.3” x 1.6”
|
|
Weight
|
3.4 lbs
|
