Tru-Vu VMTRP-10.1C-24 Panel Mount 10.1" Touch Screen Monitor
The Tru-Vu VMTRP-10.1C-24 is a high-quality panel mount touch screen monitor engineered for demanding industrial and commercial use. Featuring a brilliant 10.1-inch WXGA display with 1280 x 800 resolution and a crisp 16:9 aspect ratio, it utilizes a dependable 5-wire resistive touch screen that responds reliably to fingers, gloves, or styluses. Protected by a tough, steel-enclosed panel mount design, the VMTRP-10.1C-24 can be installed in doors, cabinets, and machinery across diverse environments, including manufacturing, military, transportation, and food processing.
This monitor is built to perform in harsh conditions, boasting 500 nits of brightness, automatic re-start after power interruptions, and TRU-Tuff shock and vibration resistance to ensure long-term reliability. Its versatile rear OSD controls allow easy operation and secure settings, while extended temperature and humidity tolerance make it suitable for nearly any installation. The VMTRP-10.1C-24 supports VGA and DVI inputs, operates on 24VDC power, and comes backed with a 3-year warranty and TAA compliance for North American applications.
Features:
- 10.1" WXGA, 1280 x 800, 16:9 aspect ratio
- 5-wire resistive touch, USB interface
- 500 nits high brightness, 800:1 contrast
- VGA & DVI video inputs
- 24 VDC operation, auto-restart
- TRU-Tuff shock/vibration resistance
- Painted steel flush-mount enclosure
- Extended operating temperature: -4° to 158°F
- TAA Compliant, 3-Year Warranty
Applications:
- Industrial Automation
- Manufacturing Displays
- Food Processing
- Military Vehicles
- Inspection Kiosks
- Transportation Panels
- Machine Interface
- Outdoor Terminals
| LCD Panel | 10.1” Color LCD; LED Backlights |
| Touch Screen Type | 5-Wire Resistive Touch |
| Touch Screen Interface | USB |
| Resolution | 1280 x 800 (WXGA) |
| Viewable Area | 9.68” W x 7.27” H (245.76 x 184.32 mm) |
| Pixel Pitch | 0.1695 mm |
| Display Colors | 16.7M |
| Aspect Ratio | 16:9 |
| Brightness | 500 nits |
| Contrast Ratio | 800:1 |
| Viewing Angle | 170° (H) x 170° (V) |
| Response Time | 25 ms (Trf) |
| Control | OSD via Rear Panel Pushbuttons |
| Video Inputs | VGA, DVI |
| Power Requirement | 24 VDC |
| Enclosure | Painted Steel Panel Mount |
| Operating Temperature | -4° to +158°F (-20° to +70°C) |
| Humidity | 5-90% RH |
| Shock | 50 G (20 ms, 1/2 sine) |
| Vibration | 1.5 G (10-200 Hz P-P) |
| Dimensions | 13.12” W x 9.44” H x 1.57” D (333.2 x 239.85 x 39.98 mm) |
| Included Accessories | VGA Cable, DVI Cable, USB Cable, 2.5mm Locking Power Pigtail |
| Warranty | 3-Year |
| Compliance | TAA |
