Tru-Vu VL-SRMHTP-43A-OF 43" Sunlight Readable Open Frame Waterproof Touch Screen Monitor
The Tru-Vu VL-SRMHTP-43A-OF is a rugged 43-inch sunlight readable open-frame touchscreen monitor designed for high-ambient light environments. With a brilliant 2,000 nits brightness—over six times that of standard displays—it delivers exceptional visibility in direct sunlight. The edge-to-edge IP65-rated all-glass front and anti-glare tempered surface ensure durability, clarity, and easy cleaning for industrial, kiosk, and outdoor use.
Built for long-term reliability, this industrial touch display integrates a projective capacitive (P-CAP) sensor that supports multi-touch and even wet-finger operation. The TRU-Tuff construction process includes silicone-sealed connections, secured wiring, and a hardened steel enclosure for superior vibration and shock resistance. This model excels in mission-critical installations where rugged performance and longevity matter most.
Features:
- 43” Full-HD 1080p LCD panel
- 2,000 nits ultra-bright sunlight-readable display
- Projected capacitive (P-CAP) multi-touch technology
- Edge-to-edge IP65 all-glass front surface
- Anti-glare, anti-reflective tempered glass
- Automated ambient light sensor adjusts brightness in real time
- TRU-Tuff process: RTV silicone sealing, wire tie-downs, ThreadLock protection
- Rugged steel enclosure for shock and vibration resistance
- Wide operating temperature range
- Supports flush-mount or open-frame integration
Applications:
- Outdoor Kiosks
- Marine Displays
- Military Systems
- Factory Automation
- Public Transit
- Digital Signage
- Vehicle Systems
- Control Rooms
| Model | Tru-Vu VL-SRMHTP-43A-OF |
| LCD Panel | 43” Color LCD; LED Backlights |
| Touch Screen Type | Projected Capacitive (P-CAP) |
| Touch Interface | USB |
| Resolution | 1920 x 1080 (Full HD 1080p) |
| Viewing Area | 37.12” (W) x 20.92” (H) / 942.9mm x 531.3mm |
| Pixel Pitch | 0.294mm |
| Display Colors | 16.7 million |
| Aspect Ratio | 16:9 |
| Brightness | 2,000 nits (sunlight readable) |
| Contrast Ratio | 3,000:1 |
| Viewing Angle | 178° (H) x 178° (V) |
| Response Time | 16 ms (Trf) |
| Video Inputs | VGA, HDMI, DVI |
| Power Requirement | 24VDC / 100–240VAC via included AC adapter |
| Power Consumption | 230W |
| Enclosure | Zero-Bezel Painted Steel |
| Enclosure Rating | IP65 (Front) |
| Mounting Options | Rear VESA 400 x 200mm & 100 x 100mm |
| Operating Temperature | 5˚ to 122˚F (-15˚ to +50˚C) |
| Weight | 70 lbs (31.5 kg) |
| Dimensions (W x H x D) | 39.75" x 23.52" x 3.45" / 1009.5mm x 597.5mm x 87.5mm |
| Warranty | 1-Year Limited Warranty |
| Notes | Specifications subject to change without notice. |
