Tru-Vu SXOBH-55-XTR 55” Outdoor Waterproof Sunlight Readable LCD Monitor

Tru-Vu SXOBH-55-XTR 55” Outdoor Waterproof Sunlight Readable LCD Monitor

Tru-Vu SXOBH-55-4 55” Outdoor Waterproof Sunlight Readable LCD Monitor/TV

Experience unparalleled clarity with our SXOBH-55-4, a 55" Outdoor Waterproof Sunlight Readable Monitor. Ideal for industrial settings, it offers 2500 nits brightness, impact-resistant glass, and advanced features for remote monitoring and reliability.
SKU
SXOBH-55-4

Unmatched Clarity in Harsh Environments

Discover cutting-edge display technology with the Tru-Vu SXOBH-55-4, a 55" Outdoor Waterproof Sunlight Readable LCD Monitor/TV designed for industrial and machine vision applications. Boasting an ultra-high brightness of 2500 nits, this monitor ensures exceptional clarity and sharpness even in direct sunlight. The Optically Bonded screen not only enhances contrast but also guarantees superior image quality. Its IP66 waterproof aluminum enclosure provides robust protection against water, moisture, and harsh environmental conditions, making it an ideal solution for challenging industrial environments.

Versatility is at its core, operating seamlessly in both Landscape and Portrait modes. The monitor features an Ambient Light Sensor for automatic brightness adjustment, ensuring optimal visibility in any lighting conditions. The impact-resistant IK10 glass, coupled with anti-reflective safety glass, safeguards against vandalism and glare. Packed with advanced features such as remote diagnostics, Auto Re-Start, and Power Scheduling, this monitor is tailored for industrial settings, offering reliability and ease of use. From military and defense applications to digital signage, sports stadiums, and inspection scenarios, the SXOBH-55-4 stands as a testament to superior outdoor display technology.

Features:

  • Ultra-Bright – 2,500 Nits Brightness
  • Optical Bonding Improves Contrast Ratio and Image Quality
  • IP 66 Waterproof Aluminum Enclosure
  • Works in Landscape and Portrait Mode
  • Ambient Light Sensor Adjusts Screen Brightness Automatically
  • Anti-Reflective, Impact-Resistant Safety Glass, Rated IK10
  • Remote Diagnostics (SNMP Protocol)
  • Auto Re-Start After Power Loss
  • 12 VDC and 5 VDC Power Outputs
  • KeyLock Function
  • Power Scheduling for auto On/Off
  • Pixel Shift to avoid image retention


Applications:

  • Industrial Machine Vision
  • Military and Defense
  • Digital Signage
  • Sports Stadiums
  • Inspection and Surveillance
  • Amusement Parks
  • Marine and Shipboard
  • Transportation Hubs (Train, Bus Stations)
LCD Panel 55"
Screen Treatment Optical Bonding
Display Resolution 1920 x 1080p Full HD
Viewable Area 47.62” (W) x 26.79” (H) (1210 x 680mm)
Display Orientation Landscape or Portrait Mode
Pixel Pitch .210 x .630mm
Display Colors 8 Bit, 16.7 Million Colors
Aspect Ratio 16:9
Brightness 2,500 nits
Contrast Ratio 2,000:1
Ambient Light Sensor Standard
Optical Bonding Standard
Viewing Angle  178° (H) x 178° (V)
Response Time 6ms (Gray to Gray)
Video Inputs HDMI (x2), Composite, DisplayPort, Component, HD Base T
Audio Outputs 3.5mm Headphone Jack & Optical
Control Remote Control with IR extender; RS-232 Control
Power Requirement 100 VAC to 240 VAC
Power Consumption Typical: 199.3W / Maximum: 215W
Enclosure / IP Rating Rugged Corrosion-Resistant Aluminum; IP66
Protective Glass 5mm Tempered Anti-Reflective Glass (IK10)
Mounting 400mm x 200mm, 400mm x 400mm , 600mm x 600mm VESA Hole Pattern
Operating Temperature -31°F to +140°F (-35°C to +60°C)
Dimensions 50.07” (W) x 29.23” (H) x 3.92" (D)
(1272 x 742 x 100 mm)
Net Weight 104.5 Lb (47.4kg)
TAA Compliant Yes
Warranty 2 Years
