Tru-Vu SRMTPWP-10.1R36 10.1” Sunlight Readable Panel Mount Waterproof Touch Screen Monitor
*Please note this product is subject to tariff fee*
Experience unparalleled clarity and durability with the Tru-Vu SRMTPWP-10.1R36 sunlight readable waterproof touch screen monitor. Perfect for industrial and outdoor applications. Order now!Exceptional Sunlight Readable Waterproof Touch Screen for Industrial Applications
Aegis Electronic Group Inc. proudly offers the Tru-Vu SRMTPWP-10.1R36, a 10.1” Sunlight Readable Panel Mount Waterproof Touch Screen Monitor designed for the most demanding industrial and machine vision applications. With a brilliant 1,200 nits brightness, this monitor produces clear, sharp images even in direct sunlight, making it perfect for outdoor environments and high ambient-light conditions. The robust NEMA 4X stainless steel panel mount enclosure ensures the monitor is waterproof, rust-proof, and corrosion-resistant, offering reliable performance in harsh conditions.
Engineered for durability, the Tru-Vu SRMTPWP-10.1R36 features the TRU-Tuff treatment for maximum shock and vibration resistance. It operates flawlessly in extreme temperatures ranging from -30°C to 80°C, ensuring consistent performance in any environment. The ambient light sensor automatically adjusts screen brightness, optimizing visibility while conserving energy.
Ideal applications for this monitor include industrial automation, machine vision systems, military and law enforcement, food processing plants, marine environments, oil and gas exploration, and transportation sectors. The monitor's auto re-start function ensures seamless recovery after power loss, providing uninterrupted operation. With a 3-year warranty and a typical MTBF of 50,000 hours, the Tru-Vu SRMTPWP-10.1R36 guarantees long-term reliability and superior imaging performance.
Features:
- 1,200 nits brightness for clear images in direct sunlight
- Stainless NEMA 4X panel-mount enclosure
- Ambient light sensor for automatic brightness adjustment
- Extreme operating temperature range: -30°C to 80°C
- Auto re-start after power loss
- TRU-Tuff treatment for shock and vibration resistance
Applications:
- Industrial automation
- Machine vision systems
- Military and law enforcement
- Food processing plants
- Marine environments
- Oil and gas exploration
- Transportation sectors
| Model | SRMTRWP-10.1R36 |
| LCD Panel | 10.1” TFT LCD; LED Backlights |
| Display Resolution | 1280 x 800 |
| Touch Screen | Projected Capacitive |
| Touch Interface | USB |
| Viewable Area | 8.54” (W) x 5.34” (H) (216.96 x 135.6 mm) |
| Pixel Pitch | 0.2175 x .2088mm |
| Display Color | 16.7 M |
| Aspect Ratio | 16:10 |
| Brightness | 1,200 nits |
| Contrast Ratio | 800:1 |
| Viewing Angle | 176° (H) x 176° (V) |
| Response Time | 13/12 (Typ.)(Tr/Td) |
| Control | OSD (On-Screen Display) via Rear Panel Pushbuttons |
| Video Inputs | VGA, HDMI & DisplayPort |
| Power Requirement | 9-36 VDC (via Phoenix Contact Connector) |
| Power Consumption | 15 Watts |
| Enclosure | Stainless Steel Panel-Mount, with Rear Clamp |
| Enclosure Rating | NEMA 4X; Front: IP65 |
| Operating Temperature | -22° to 176° F (-30° to +80° C) |
| Humidity | 5-90% RH |
| Shock | 50 G (20 msec, 1/2 sine) |
| Vibration | 1.5G RMS 10-200 HZ |
| Dimensions | 12.57" W x 9.29" H x 1.89" D (319.20mm W x 235.96mm H x 48mm D) |
| Weight | 6.6 lbs (3 kg) |
