Tru-Vu SRMOB-10.4N2-36 10.4” Sunlight Readable Optically Bonded Monitor
SKU
SRMOB-10.4N2-36
$1,045.00
Quick Overview
A rugged 10.4” high brightness display with optical bonding, anti-reflective glass, and 1,500 nits brightness for clear visibility in direct sunlight. Built for demanding industrial environments with extreme temperature tolerance and TRU-Tuff durability.
The Tru-Vu SRMOB-10.4N2-36 delivers superior visual performance in direct sunlight with 1,500 nits brightness and optical bonding technology for enhanced contrast and clarity. Engineered with industrial-grade materials and TRU-Tuff reinforcement, it endures extreme temperatures, shock, and vibration.
It's 4:3 aspect ratio, anti-reflective glass, and wide viewing angles make it an ideal choice for outdoor and mission-critical applications where reliable visibility is essential. Built for military, transportation, and marine environments, this TAA-compliant monitor ensures operational dependability anywhere it’s deployed.
Features:
- 10.4” SVGA (800x600) LCD with Optical Bonding
- Sunlight Readable with 1,000 or 1,500 nits Brightness
- TRU-Tuff Construction for Shock and Vibration Resistance
- -22°F to +176°F Operating Temperature Range
- Anti-Reflective Glass for Glare Reduction
- Rugged Painted Steel Enclosure with 75x75mm VESA Mount
- Auto Re-Start After Power Loss
- Lockable OSD Controls
- 11–36VDC Power Input (Locking Barrel Plug)
- 3-Year Warranty
Applications:
- Military Displays
- Marine Navigation
- Industrial Control
- Vehicle Systems
- Outdoor Kiosks
- Transportation Panels
- Security Stations
- Crane Controls
| LCD Panel | 10.4” Color LCD; LED Backlights |
| Screen Treatment | Optical Bonding |
| Front Glass | Anti-Reflective |
| Resolution | 800 x 600 (SVGA) |
| Viewable Area | 8.31” (W) x 6.24” (H) (211.2 x 158.4 mm) |
| Pixel Pitch | 0.264 mm |
| Display Colors | 16.2 Million |
| Aspect Ratio | 4:3 |
| Brightness | 1,000 or 1,500 nits |
| Contrast Ratio | 3,000:1 / 700:1 |
| Viewing Angle | 160° (H) x 140° (V) |
| Response Time | 15 ms |
| Controls | OSD via Rear Panel Pushbuttons |
| Video Inputs | Composite BNC x2, VGA, BNC Loop-thru |
| Power Requirement | 11–36VDC (2.5mm Locking Barrel Plug) |
| Power Consumption | 16W |
| Enclosure | Painted Steel |
| Mounting | 75 x 75 mm Rear VESA (M4 x 6mm Screws) |
| Operating Temperature | -22°F to +176°F (-30°C to +80°C) |
| Humidity | 5 - 90% RH |
| Shock | 50G, 20ms, Half-sine wave |
| Vibration | 1.5G (10–200 Hz, P–P) 30 mins./axis |
| Dimensions | 10.13” (W) x 7.96” (H) x 1.73” (D) |
| Weight | 3.86 lbs. (1.75 kg) |
| Warranty | 3 Years |
