TRU-Vu MMZB-23.8G-X 23.8" Medical Grade Full HD Zero-Bezel Monitor

The TRU-Vu MMZB-23.8G-X is a 23.8-inch medical grade monitor designed for hospitals, operating rooms, medical carts, PACS workstations, endoscopy systems, fluoroscopy systems, medical imaging equipment and OEM medical device integration. Built for healthcare environments where image clarity, hygiene and long-term reliability matter, this medical display combines Full HD resolution, wide viewing angles, a zero-bezel front surface and medical-grade electrical compliance.

This 23.8" medical monitor features a 1920 x 1080 Full HD AHVA panel with LED backlights, 400-nit brightness, a 1,000:1 contrast ratio and 16.7 million display colors. The 178° horizontal and vertical viewing angles help maintain clear image visibility from multiple positions, making it a strong choice for clinical workstations, surgical rooms, mobile carts and shared viewing environments.

The MMZB-23.8G-X is engineered for professional medical environments and conforms to important medical electrical safety and EMC requirements, including UL 60601-1 Edition 3.1 and IEC 60601-1-2 4th Edition. It includes a medical-grade external power supply with a locking connector and green dot power cord for dependable operation in healthcare facilities and OEM medical systems.

The monitor’s zero-bezel front design provides a smooth, flat front surface that is easier to wipe down than traditional raised-bezel monitors. With fewer edges where dust, fluids and contaminants can collect, the MMZB-23.8G-X is well suited for hospitals, procedure rooms, laboratories, clean environments and medical carts that require frequent cleaning. The front panel is rated IP65, while the rear enclosure is rated IP30.

The fanless design helps improve reliability by eliminating a moving part that can fail over time. It also supports quieter operation and helps reduce the circulation of dust or airborne particles, which is important in sensitive medical and clinical environments. The white ABS enclosure with rounded edges provides a clean, professional look for healthcare installations.

With HDMI, DVI and DisplayPort inputs, the MMZB-23.8G-X can connect to a wide range of medical imaging systems, embedded computers, video sources, clinical workstations and OEM equipment. Built-in dual rear speakers can support system tones, alerts and audio feedback. Rear 100mm x 100mm VESA mounting holes allow installation on medical carts, spring arms, surgical booms, wall mounts or optional tabletop bases.

Key Features:

• 23.8" medical grade Full HD monitor
• 1920 x 1080 resolution at 1080p/60
• 400-nit brightness and 1,000:1 contrast ratio
• 178° horizontal and vertical viewing angles
• Zero-bezel front glass for easier cleaning and improved hygiene
• IP65-rated front panel and IP30-rated rear enclosure
• White ABS enclosure for medical environments
• Fanless design for quiet, reliable operation
• HDMI, DVI and DisplayPort video inputs
• Built-in dual rear speakers
• Auto restart after power loss
• 100mm x 100mm VESA mounting pattern
• Medical-grade external power supply with locking connector
• TAA compliant
• 3-year warranty

Applications:

• Hospital operating rooms
• Surgical display systems
• Medical carts and mobile workstations
• Endoscopy systems
• Fluoroscopy systems
• PACS viewing stations
• Medical imaging equipment
• Patient monitoring systems
• Clinical workstations
• OEM medical device integration
• Laboratory and healthcare equipment
• Cleanroom and sterile display environments
