Theia ML410A R5 True 4K Standard Focal Range Lens
Unrivaled Precision in Industrial Imaging: Theia ML410A R5 True 4K Standard Focal Range Lens
Introducing the Theia ML410A R5, a cutting-edge True 4K Standard Focal Range Lens designed for the demanding requirements of industrial and machine vision applications. With an ultra-high resolution of 12 megapixels, this lens ensures exceptional clarity and precision in imaging, making it ideal for applications where image detail is crucial.
The 4-10 mm focal range provides versatility, catering to various scenarios within industrial environments. The lens is IR corrected for Day/Night functionality, guaranteeing optimal performance in diverse lighting conditions. Its compatibility with 1/1.7" sensor sizes or smaller makes it a versatile choice for a range of camera setups.
The compact design of the ML410A R5 is specifically tailored for small dome cameras (4" dome size) and bullet cameras, offering flexibility in installation without compromising on image quality. The manual iris control allows fine-tuning of the aperture, providing adaptability to different lighting conditions.
Equipped with a C-mount, the ML410A R5 ensures a secure and standardized connection to your industrial camera system. The inclusion of a photo interrupter further enhances its functionality in various applications. Whether used for surveillance, quality control, or automated inspection, this lens sets a new standard for True 4K imaging in the industrial and machine vision domain.
Features:
- True 4K Resolution (12 megapixels)
- Versatile 4-10mm Focal Range
- IR Corrected for Day/Night Vision
- Compact Design for Small Dome and Bullet Cameras
- Manual Iris Control (F/1.4 to closed)
- C-mount Compatibility
- Photo Interrupter for Enhanced Functionality
- Ideal for 1/1.7" Sensor Sizes or Smaller
- Unrivaled Precision in Industrial Imaging
- Suitable for Surveillance, Quality Control, and Automated Inspection
- Elevate Your Imaging with Theia's Cutting-edge Technology
Applications:
| ML410A R5 | |
| Mount Type | C-Mount |
| Iris Type | Manual Iris |
| Focal Length | 4-10mm |
| Image Circle | Ø9.4mm |
| Resolution | 12.4 megapixel |
| F/# | F/1.4 @ 4mm – F/2.4 @ 10mm to close |
| Focus Range | 0.5m to infinity |
| IR Correction | Day/Night |
| Lens Length | < 64mm TTL |
| Weight | 69-78g (depending on version) |
| Operating Temperature | -20C to 60C (<70% humidity, non-condensing) |
| Storage Temperature | -30C to 70C (<90% humidity, non-condensing) |
