OPTOWL FL-CC6Z1218A-VG | 2/3" 12.5-75mm VGA Manual Zoom & Iris Camera
RICOH FL-CC6Z1218A-VG: High-Performance Lens for Machine Vision Applications
The RICOH FL-CC6Z1218A-VG is a robust and versatile lens specifically designed for demanding machine vision applications. Featuring a 2/3" sensor format and a variable focal length of 12.5-75mm, this lens delivers exceptional image clarity and precision. It is equipped with a manual iris for optimal control over light exposure, making it adaptable to various lighting conditions. The lens also includes locking screws to ensure stable performance and reduce vibrations, which is crucial in high-speed or high-precision environments.
As part of Ricoh’s esteemed VGA lens family, the FLCC6Z1218AVG is engineered to work seamlessly with VGA-class cameras. Its compatibility extends to handling cameras with sensor formats ranging from 1/2" to 1", making it a flexible choice for a range of machine vision systems. This lens is an ideal solution for applications requiring detailed and accurate image acquisition.
Features:
- Standard lenses for machine vision use
- Compatible with VGA-class cameras
- Production line handling cameras from 1/2" to 1" formats
- Lock screws as standard vibration-control measures
Applications:
- pattern matching
- component positioning
- missing-part inspection
- board mounting
- inspection of pharmaceuticals
- produce
- grains
| Format size | 2/3, 1/2, 1/3" format |
| Focal length | 12.5-75 mm |
| Maximum aperture ratio | 1:1.8 |
| Iris range | 1.8-22 |
| Mount | C |
| Horizontal Angle of View - 1/4" format | 16.1-2.7° |
| Horizontal Angle of View - 1/3" format | 21.4-3.7° |
| Horizontal Angle of View - 1/2" format | 28.4-4.9° |
| Horizontal Angle of View - 2/3" format | 38.8-6.7° |
| Minimum object distance | 1.0 m |
| Back focal length | 18.41 mm |
| Filter size | 49 P=0.75 mm |
| Dimensions | φ51x90 mm |
| Weight | 320 g |
| Remarks | Manual Iris: FL-CC6Z1218-VG Manual Iris, Locking Screws(zoom and focus only): FL-CC6Z1218A-VG |
