Pleora vDisplay HDI-Pro (930-1001) External Frame Grabber
*Please note tariff fee is included in price*
Pleora vDisplay HDI-Pro (930-1001) delivers real-time GigE Vision® camera video to HDMI/DVI displays with low latency—eliminating PCs at the monitor for higher reliability and lower power in industrial systems.
Pleora vDisplay HDI-Pro (930-1001) is a compact, solid-state external frame grabber designed to display GigE Vision® camera streams directly on HDMI/DVI monitors—without relying on a PC at the monitor. By converting incoming IP video packets into HDMI/DVI-compatible signals with low, consistent latency, it improves uptime and simplifies deployments where reliability, size, weight, and power draw matter most.
Built for 24/7 industrial viewing, the 9301001 reduces energy consumption (approximately 3.2 W typical) and boots in seconds for faster recovery versus OS-based PCs. It integrates cleanly into networked digital video systems and supports GenICam™ interoperability, enabling multi-vendor setups while maintaining plug-and-play camera control and persistent configuration via Pleora’s eBUS™ SDK or other GenICam-compliant tools.
Features:
- SKU-first solution: Pleora 930-1001 vDisplay HDI-Pro external frame grabber
- GigE Vision® to HDMI/DVI real-time video output
- Low, consistent latency for dependable monitoring
- Solid-state design replaces PCs at display stations
- Auto-senses monitor resolution and refresh rate
- Autonomous camera control (no software control app required)
- GenICam™ compliant for multi-vendor interoperability
- Supports Bayer, RGB, YUV, monochrome pixel formats
- Persistent memory stores configuration settings
- Long-reach Ethernet (100 m point-to-point; more with switches/fiber)
Applications:
- Machine Vision
- Factory Automation
- Robotic Inspection
- Process Monitoring
- Remote Viewing
- Quality Control
Key Functionality | •Highly reliable, 1 Gb/s data reception rate with low latency |
Camera Type Support | •Area scan and linescan |
Monitor Support | •Interoperates with VESA compliant single link monitors •Auto-senses monitor display capabilities •Can interoperate with custom displays by manually configuring display timing parameters |
Power | •12-pin Hirose (HR10A-10R-12PB) |
Network | •RJ-45 |
Video output | •HDMI/DVI |
Setup and advanced configuration | •Via eBUS™ SDK or any GenICam compliant application •Settings can be stored in persistent memory •Plug-and-play autonomous control of GigE Vision compliant camera |
GigE-Based | •10/100/1000 Mb/s •IEEE 802.3 (Ethernet), IPv4, IGMPv2, UDP, ICMP (ping), DHCP, and jumbo packets •Long reach: 100 m point-to-point, further with Ethernet switches or fiber |
GigE Vision Protocol | •GigE Vision Streaming Protocol (GVSP) •GigE Vision Control Protocol (GVCP) |
Size (L x W x H) | •Enclosed unit: 81 mm X 59 mm X 40 mm •OEM board set: 81 mm X 51 mm X 26 mm |
Operating temperature | •Enclosed unit: 0°C to 55°C •OEM board set: 0°C to 44°C |
Storage temperature | •-40°C to 85°C |
Power Supply | •5 V to 16 V |
Power Consumption | •3 W to 4.3 W (temperature and input voltage dependent) |
ORDERING INFORMATION | |
930-1001 | •vDisplay HDI-Pro External Frame Grabber enclosed product |
930-1002 | •vDisplay HDI-Pro External Frame Grabber Evaluation Kit, containing 930-1001 and power supply |
