Omron STC-S133UVC-ALL UVC 1.3 MP, 1/3.2" Sony ISX017 CMOS, 60fps, USB 3.0, S Mount Board Level Area Scan Camera
*Please note tariff fee is included in price*
Omron STC-S133UVC-ALL: 1.3 MP color camera with UVC interface, 1280 x 960 resolution, 60 fps, rolling shutter, 1/3.2" ISX017 sensor, 3.5 µm pixels, S-mount, and IR cut filter. NDAA CompliantThe Omron STC-S133UVC-ALL is a high-performance 1.3 MP color camera designed for seamless integration into machine vision, industrial, and research applications. Featuring a UVC-compliant interface, it ensures effortless connectivity across various platforms without the need for proprietary drivers. With a compact 1/3.2" ISX017 image sensor, the camera delivers sharp, high-quality visuals at a resolution of 1280 x 960 pixels, making it ideal for applications requiring precise detail capture.
The rolling shutter design supports a fast 60 frames per second (fps) output, ensuring smooth and efficient image acquisition for dynamic scenes. The 3.5 µm pixel size ensures excellent light sensitivity and accurate color reproduction, supported by an integrated IR cut filter for optimal performance in visible light environments. This area scan camera is equipped with an S-mount lens interface, offering compatibility with a wide range of lenses to suit diverse application needs.
Features:
- 1.3 MP resolution
- UVC interface
- 1280 x 960 pixels
- 60 fps frame rate
- Rolling shutter
- S-mount lens compatibility
- IR cut filter
- 1/3.2" ISX017 sensor
Applications:
| Model Number | STC-S133UVC-ALL |
| Frame Rate | 60 FPS |
| Mono/Color | Color |
| Pixel Size (HxV) | 3.5 x 3.5 µm |
| Resolution | 1.3 MP |
| Resolution (HxV) | 1280 x 960 |
| Sensor Name | ISX017 |
| Sensor Size | 1/3.2" |
| Sensor Type | CMOS |
| Interface | UVC |
| Shutter Type | Rolling Shutter |
| Type | Cased |
| Lens Mount Type | M12-Mount |
| Dimensions | 25 (W) x 25 (H) x 18 (D) mm |
