Kowa LM35FC24M | 1.1" 35mm 24MP C-mount Lens
Enhance Your Machine Vision System with the Kowa LM35FC24M 24MP C-Mount Lens
Aegis Electronic Group Inc. proudly offers the Kowa LM35FC24M 1.1" 35mm 24MP C-mount lens, a pinnacle of precision and reliability in the realm of machine vision and industrial applications. Designed for sensors with a pixel size of 2.5μm, this lens is perfectly suited for Sony IMX531, IMX183, and IMX304 sensors, among others. The Kowa LM35FC24M excels in delivering high-resolution imagery with its impressive 200 lp/mm center resolution and 100 lp/mm corner resolution. Its broad wavelength range (380nm - 1000nm) ensures exceptional performance across visible and broad band spectrums.
This lens is an ideal choice for demanding industrial environments, offering a robust design with manual iris and focus controls, an iris range of F1.8 to F16, and a focusing range from 0.2 meters to infinity. Its distortion-free performance (0.01% TV distortion) ensures the utmost accuracy, making it a reliable asset for ITS/traffic control, broadcast, and other machine vision applications. The Kowa LM35FC24M's compact size (Ø45 x 66mm) and lightweight (205g) design facilitate easy integration into various systems, providing the perfect balance of quality, durability, and functionality.
Upgrade your imaging capabilities with the Kowa LM35FC24M and experience unparalleled clarity and precision in your machine vision projects.
Features:
- 35mm focal length
- 1.1" sensor compatibility
- 24MP resolution
- Manual iris and focus control
- High center and corner resolution
- Broad wavelength range (380nm - 1000nm)
- Compact and lightweight design
Applications:
- Intelligent Transportation Systems (ITS)
- Traffic control
- Machine vision inspection
- Broadcast imaging
- Industrial automation
- Quality control systems
- High-precision manufacturing
| Focal Length (mm) | 35 |
| Sensor Size | 1.1" |
| Pixel Size (µm) | 2.5 |
| Mount | C-Mount |
| Iris Control | Manual |
| Iris Range (F-Stop) | 1.8 - 16 |
| Lens Type | Fixed Focal Lens |
| Wavelength Range | VIS (380nm - 780nm), Broad Band Coating (380nm - 1000nm) |
| Focusing range (m) | 0,2 - ∞ |
| Focus Control | Manual |
| Shooting range at MOD, horizontal (mm) | 84 |
| Shooting range at MOD, vertical (mm) | 63 |
| Resolution (Center, Corner) | 200lp/mm,100lp/mm |
| Megapixel | 24 |
| TV Distortion (%) | 0.01 |
| Back Focus in Air (mm) | 15.5 |
| Filter Size (mm) | M40.5 x P0,5 |
| Size (mm) | Ø45 X 66 |
| Weight | 205 |
| Temperature Range | -10°C - +50°C |
| Series | FC24M |
| Application | ITS/Traffic Control, Machine Vision, Broadcast |
