Kowa LM12JC5M2 | 2/3" 12.5mm 5MP C-Mount Lens
Enhance Your Vision with Kowa LM12JC5M2 5MP C-Mount Lens
Aegis Electronic Group Inc. is proud to offer the Kowa LM12JC5M2 2/3" 12.5mm 5MP C-Mount Lens, an exceptional choice for industrial and machine vision applications. This high-resolution lens is designed for sensors with a pixel size of 3.5μm or more, making it suitable for use with popular sensors like the Sony IMX174, IMX252, and IMX273. Its fixed focal length of 12.5mm ensures precise and sharp imaging, ideal for detailed inspection tasks and quality control processes.
The Kowa LM12JC5M2 features manual iris control with an iris range from f/1.4 to f/16, allowing users to adjust the aperture for optimal image brightness and depth of field. The lens is equipped with a broad band coating, covering a wavelength range from 380nm to 1000nm, ensuring superior performance across various lighting conditions.
With a compact design (Ø38.5mm x 55.7mm) and robust build, this lens is perfect for harsh industrial environments, operating reliably within a temperature range of -10°C to +50°C. Applications benefiting from this lens include Intelligent Transportation Systems (ITS), traffic control, and diverse machine vision tasks, providing high-resolution images critical for accurate analysis and decision-making.
Features:
- 2/3" 5MP C-mount industrial lens
- 12.5mm focal length
- Compatible with sensors like Sony IMX174, IMX252, and IMX273
- Manual iris control (f/1.4 - f/16)
- Broad band coating (380nm - 1000nm)
- Compact and robust design
- Operating temperature: -10°C to +50°C
Applications:
- Intelligent Transportation Systems (ITS)
- Traffic control
- Machine vision tasks
- Quality control processes
- Detailed inspection tasks
- Industrial automation
| Focal Length (mm) | 12.5 mm |
| Sensor Size | 2/3" |
| Pixel Size (µm) | 3,5 |
| Mount | C-Mount |
| Iris Control | Manual |
| Iris Range (F-Stop) | 1,4 - 16 |
| Lens Type | Fixed Focal Lens |
| Wavelength Range | Broad Band Coating (380nm - 1000nm), VIS (380nm - 780nm) |
| Focusing range (m) | 0,1 - ∞ |
| Focus Control | Manual |
| Shooting range at MOD, horizontal (mm) | 81,4 |
| Shooting range at MOD, vertical (mm) | 60,9 |
| Resolution (Center, Corner) | 160lp/mm,125lp/mm |
| Megapixel | 5 |
| TV Distortion (%) | -0,06 |
| Back Focus in Air (mm) | 11,5 |
| Filter Size (mm) | M30,5 x P0,5 |
| Size (mm) | Ø38,5 X 55,7 |
| Weight | 130 |
| Temperature Range | -10°C - +50°C |
| Series | JC5M2 |
| Application | ITS/Traffic Control, Machine Vision |
