IPX NMG-342M5XH-W 3MP Global Shutter IP Camera Module with 6-22mm Motorized Zoom Lens, 42x42mm Single Board

The IPX NMG-342M5XH-W is a 3MP global shutter IP camera module with a 6-22mm motorized zoom lens, designed for embedded vision systems that require adjustable field-of-view control, edge AI support, and reliable image capture of moving subjects. Its compact 42 x 42mm single-board design makes it suitable for robotics, UAV/drone platforms, machine vision, intelligent transportation, surveillance, remote monitoring, and industrial inspection.

Unlike fixed-lens versions, the NMG-342M5XH-W provides flexible optical framing with its 6-22mm zoom lens. This makes it a strong option for applications where operators or systems need to shift between wider situational awareness and more detailed target viewing. The Sony 1/3" 3MP global shutter sensor helps reduce rolling shutter distortion, making the module useful for motion-heavy applications such as moving platforms, conveyor systems, traffic lanes, and mobile robotics.

Powered by a 64-bit Quad Core RISC-V SoC running embedded Linux, the NMG-342M5XH-W supports H.265, H.264, and MJPEG video compression. Integrated NPU support for MobileNet V2 + SSDLite and YOLO7 object detection allows this camera module to be used in AI-enabled embedded systems where intelligent object recognition and compact board-level integration are required.

Key Features:

• 3MP global shutter IP camera module with 6-22mm motorized zoom lens
• Sony 1/3" 3M Pixel global shutter image sensor
• Adjustable optical zoom for flexible scene coverage and target detail
• 42 x 42mm compact single-board camera format
• 64-bit Quad Core RISC-V SoC with embedded Linux
• H.265, H.264, and MJPEG compression
• Up to 2048 x 1536 resolution at 30fps based on provided video specification
• NPU support for MobileNet V2 + SSDLite and YOLO7 object detection
• Trigger input and Flash / IR output for synchronized imaging
• Image processing controls include sharpness, brightness, contrast, HLC, BLC, WDR, 2DNR, and 3DNR

Applications:

• Robotics and autonomous vehicle vision
• UAV/drone inspection with adjustable viewing range
• Industrial inspection and quality control
• Machine vision systems requiring optical zoom flexibility
• Intelligent traffic and transportation monitoring
• Security, surveillance, and remote situational awareness
• AI object detection and edge analytics
• Perimeter monitoring and infrastructure inspection
