IPX NMG-342M4XH-W 3MP Global Shutter IP Camera Module with 2.7-13.5mm Motorized Zoom Lens, 42x42mm Single Board

The IPX NMG-342M4XH-W is a compact 3MP global shutter IP camera module featuring a 2.7-13.5mm motorized zoom lens for flexible embedded vision applications. Designed around a Sony 1/3" 3MP global shutter image sensor, this single-board camera module delivers reduced motion distortion, efficient IP video compression, and onboard AI object detection support in a compact 42 x 42mm format.

The 2.7-13.5mm zoom lens gives this model a versatile viewing range, making it useful for systems that need both wider scene coverage and adjustable close-in detail. It is well suited for robotics, UAV/drone imaging, intelligent traffic systems, machine vision, security, surveillance, and industrial inspection applications where field-of-view flexibility is important.

With a 64-bit Quad Core RISC-V SoC, embedded Linux, H.265/H.264/MJPEG support, trigger input, Flash / IR output, and NPU compatibility with MobileNet V2 + SSDLite and YOLO7 object detection, the NMG-342M4XH-W provides an AI-ready IP camera module for OEMs, integrators, and embedded vision developers.

Key Features:

• 3MP global shutter IP camera module with 2.7-13.5mm motorized zoom lens
• Sony 1/3" 3M Pixel global shutter sensor for motion-sensitive imaging
• Versatile zoom range for wide coverage and adjustable target viewing
• Compact 42 x 42mm single-board camera design
• 64-bit Quad Core RISC-V SoC running embedded Linux
• H.265, H.264, and MJPEG video compression support
• Up to 2048 x 1536 resolution at 30fps based on provided video specification
• Integrated NPU support for MobileNet V2 + SSDLite and YOLO7 object detection
• Trigger input and Flash / IR output for synchronized vision systems
• Image adjustment features include WDR, HLC, BLC, 2DNR, 3DNR, sharpness, brightness, and contrast

Applications:

• Robotics and autonomous equipment imaging
• UAV/drone vision with adjustable field of view
• Industrial inspection and factory automation
• AI object detection and smart camera systems
• Machine vision and process monitoring
• Intelligent traffic and smart city applications
• Surveillance and remote monitoring
• Medical, laboratory, and research imaging platforms
