IPX NMG-342M10XH-W 3MP Global Shutter IP Camera Module with 5-50mm Motorized Zoom Lens, 42x42mm Single Board
The IPX NMG-342M10XH-W is a 3MP global shutter IP camera module with a 5-50mm motorized zoom lens, built for applications that require long-range viewing, adjustable optical zoom, intelligent video processing, and compact embedded integration. Featuring a Sony 1/3" 3MP global shutter image sensor, this module is designed to reduce motion artifacts while supporting detailed capture of moving subjects, distant targets, or defined inspection zones.
The 5-50mm motorized zoom lens makes the NMG-342M10XH-W the best fit in this series for narrow field-of-view applications, longer-distance monitoring, inspection, intelligent traffic, perimeter surveillance, and target-focused machine vision. Its compact 42 x 42mm single-board design makes it useful for OEM systems, robotics, UAV/drone payloads, remote monitoring, industrial automation, and AI-enabled smart camera platforms.
Powered by a 64-bit Quad Core RISC-V SoC with embedded Linux, the NMG-342M10XH-W supports H.265, H.264, and MJPEG video compression. Integrated NPU support for MobileNet V2 + SSDLite and YOLO7 object detection helps enable edge AI image analysis in compact camera systems where zoom flexibility and global shutter performance are required.
Key Features:
- 3MP global shutter IP camera module with 5-50mm motorized zoom lens
- Longer-range optical zoom for targeted monitoring and detailed capture
- Sony 1/3" 3M Pixel global shutter image sensor
- Compact 42 x 42mm single-board camera module
- 64-bit Quad Core RISC-V SoC with embedded Linux
- H.265, H.264, and MJPEG video compression
- Up to 2048 x 1536 resolution at 30fps based on provided video specification
- NPU support for MobileNet V2 + SSDLite and YOLO7 object detection
- Trigger input and Flash / IR output for synchronized imaging applications
- Video processing includes WDR, HLC, BLC, 2DNR, 3DNR, brightness, contrast, and sharpness controls
Applications:
- Long-range surveillance and remote monitoring
- Intelligent traffic and transportation imaging
- UAV/drone inspection and target observation
- Robotics and autonomous systems requiring optical zoom
- Industrial inspection and machine vision
- AI object detection and edge analytics
- Perimeter monitoring and infrastructure security
- Factory automation and process control
| Manufacturer / Brand | IPX / Infinite Pixels |
| Model Number | NMG-342M10XH-W |
| Camera Type | 3MP IP Camera Module |
| Board Type | Single Board |
| Resolution | 3MP |
| Image Sensor | Sony 1/3" 3M Pixel Global Shutter Sensor |
| Shutter Type | Global Shutter |
| SoC | 64-bit Quad Core RISC-V |
| Operating System | Embedded Linux |
| Video Compression | H.265, H.264, MJPEG |
| Maximum Video Output | Up to 2048 x 1536 @30fps |
| NPU / AI Support | MobileNet V2 + SSDLite / YOLO7 Object Detection |
| Included Lens | 5-50mm Motorized Zoom Lens |
| Lens Options | 2.8mm / 6mm / 8mm Fixed Focus Lens / 3x & 10x Motorized Zoom Lens |
| Interfaces | Trigger In, Flash / IR Out |
| Video Processing | Sharpness, Brightness, Contrast, HLC, BLC, WDR, 2DNR, 3DNR |
| Board Dimensions | 42 x 42mm |
| Recommended Use | Long-Range Surveillance, UAV/Drone, Robotics, Machine Vision, Intelligent Traffic, AI, Industrial Inspection |
