IPX NMG-342B60H-W 3MP Global Shutter IP Camera Module with 6mm Lens, 42x42mm Single Board
IPX NMG-342B60H-W 3MP global shutter IP camera module with 6mm lens, Sony 1/3" image sensor, embedded Linux, 64-bit Quad Core RISC-V SoC, H.265/H.264/MJPEG video, AI object detection support, trigger input, Flash/IR output, and 42 x 42mm single-board design for machine vision and embedded imaging.
The IPX NMG-342B60H-W is a compact 3MP global shutter IP camera module engineered for embedded imaging applications that require reduced motion distortion, efficient IP video streaming, and AI-enabled object detection. Built around a Sony 1/3" 3MP global shutter sensor, this 42 x 42mm single-board camera is designed for robotics, UAV/drone systems, intelligent traffic monitoring, industrial inspection, machine vision, and security applications.
This model includes a 6mm fixed focus lens, providing a narrower field of view than the 2.8mm and 4mm versions. The 6mm lens is ideal for applications where the camera needs to capture more detail at distance, monitor defined zones, inspect specific targets, or identify objects within a more controlled viewing area.
The NMG-342B60H-W uses a 64-bit Quad Core RISC-V SoC with embedded Linux and supports H.265, H.264, and MJPEG compression for flexible IP video integration. With onboard NPU support for MobileNet V2 + SSDLite and YOLO7 object detection, this module helps OEMs and system integrators build intelligent vision systems in a compact industrial-ready camera format.
Key Features
- 3MP global shutter IP camera module for motion-sensitive imaging
- 6mm fixed focus lens for tighter scene coverage and longer-range detail
- Sony 1/3" 3M Pixel global shutter image sensor
- Compact 42 x 42mm single-board camera design
- 64-bit Quad Core RISC-V SoC with embedded Linux
- H.265, H.264, and MJPEG video support
- Up to 2048 x 1536 resolution at 30fps based on provided video specification
- Integrated NPU support for MobileNet V2 + SSDLite and YOLO7 object detection
- Trigger input and Flash / IR output for synchronized machine vision systems
- Advanced image controls including HLC, BLC, WDR, 2DNR, 3DNR, sharpness, brightness, and contrast
Applications
- Targeted industrial inspection
- Machine vision and quality control
- Robotics and autonomous system imaging
- UAV/drone inspection where tighter viewing angles are needed
- Traffic monitoring and lane-focused imaging
- AI object detection and smart camera systems
- Security and perimeter monitoring
- Factory automation and process monitoring
| Manufacturer / Brand | IPX / Infinite Pixels |
| Model Number | NMG-342B60H-W |
| Camera Type | 3MP IP Camera Module |
| Board Type | Single Board |
| Resolution | 3MP |
| Image Sensor | Sony 1/3" 3M Pixel Global Shutter Sensor |
| Shutter Type | Global Shutter |
| SoC | 64-bit Quad Core RISC-V |
| Operating System | Embedded Linux |
| Video Compression | H.265, H.264, MJPEG |
| Maximum Video Output | Up to 2048 x 1536 @30fps |
| NPU / AI Support | MobileNet V2 + SSDLite / YOLO7 Object Detection |
| Included Lens | 6mm Fixed Focus Lens |
| Lens Options | 2.8mm / 6mm / 8mm Fixed Focus Lens / 3x & 10x Motorized Zoom Lens |
| Interfaces | Trigger In, Flash / IR Out |
| Video Processing | Sharpness, Brightness, Contrast, HLC, BLC, WDR, 2DNR, 3DNR |
| Board Dimensions | 42 x 42mm |
| Recommended Use | Machine Vision, Robotics, UAV/Drone, Intelligent Traffic, AI, Surveillance, Industrial Inspection |
