IPX NMG-242M5XH-W 2MP Global Shutter IP Camera Module, 42x42mm Double Board, 6-22mm Motorized Lens

The IPX NMG-242M5XH-W is a 2MP global shutter IP camera module with a 6-22mm motorized zoom lens, designed for embedded vision applications that need remote lens adjustment, flexible field-of-view control, and reduced motion distortion. Built with the ONSEMI AR0234 1/2.6" 2MP global shutter sensor, this module is ideal for robotics, UAV/drone payloads, intelligent traffic, machine vision, remote monitoring, AI vision, and inspection systems.

The motorized lens gives system designers more flexibility than fixed-lens modules, allowing the camera to adjust between wider monitoring and tighter target detail depending on the application. Combined with Embedded Linux, a 64-bit Quad Core RISC-V SoC, H.265/H.264/MJPEG compression, trigger input, Flash/IR output, and AI object detection support, the NMG-242M5XH-W is built for smart, compact, and configurable IP camera systems.

Key Features:

• 2MP global shutter IP camera module with motorized zoom lens
• 6-22mm motorized lens for adjustable field-of-view control
• ONSEMI AR0234 1/2.6" 2MP global shutter sensor
• Compact 42 x 42mm double-board camera design
• 64-bit Quad Core RISC-V SoC and Embedded Linux
• H.265, H.264, and MJPEG video compression
• AI object detection support using MobileNet V2 + SSDLite / YOLOv7
• Trigger input and Flash/IR output for synchronized imaging
• WDR, HLC, BLC, 2DNR, 3DNR, sharpness, brightness, and contrast controls
