IPX NMG-242M10XH-W 2MP Global Shutter IP Camera Module, 42x42mm Double Board, 5-50mm Motorized Lens

The IPX NMG-242M10XH-W is a 2MP global shutter IP camera module featuring a powerful 5-50mm motorized zoom lens for applications that need adjustable long-range detail capture in a compact embedded camera design. Built with the ONSEMI AR0234 1/2.6" 2MP global shutter sensor, this module helps reduce motion distortion in machine vision, robotics, UAV/drone, traffic, surveillance, inspection, and remote monitoring applications.

The 5-50mm motorized lens makes this model the best fit in the NMG-242 series when the application requires tighter zoom, longer working distances, or remote field-of-view adjustment. With Embedded Linux, a 64-bit Quad Core RISC-V SoC, H.265/H.264/MJPEG compression, AI object detection support, trigger input, and Flash/IR output, the NMG-242M10XH-W is designed for advanced smart camera systems and high-performance industrial IP imaging.

Key Features:

• 2MP global shutter IP camera module with 5-50mm motorized zoom lens
• Ideal for longer-range detail capture and remote monitoring
• ONSEMI AR0234 1/2.6" 2MP global shutter image sensor
• Compact 42 x 42mm double-board design
• 64-bit Quad Core RISC-V SoC with Embedded Linux
• H.265, H.264, and MJPEG video compression
• AI object detection support using MobileNet V2 + SSDLite / YOLOv7
• Trigger input and Flash/IR output for synchronized imaging
• Video processing: sharpness, brightness, contrast, HLC, BLC, WDR, 2DNR, and 3DNR
