IPX NMG-1242M5X-W 12MP Global Shutter IP Camera Module, 42x42mm Double Board, 6-22mm Motorized Lens
The IPX NMG-1242M5X-W is a compact 12MP global shutter IP camera module with a 6-22mm motorized lens, designed for embedded vision systems that need flexible framing, remote zoom control, high-resolution capture, and onboard AI object detection. This model is a strong choice for UAV/drone payloads, robotics, smart surveillance, intelligent transportation, industrial inspection, and AI-enabled monitoring systems.
The module uses a Sony 1/1.1” 12MP global shutter CMOS sensor to help reduce distortion when capturing motion, moving equipment, vehicles, conveyor lines, or aerial scenes. The onboard 64-bit Quad Core RISC-V SoC runs embedded Linux and supports efficient video streaming using H.265, H.264, and MJPEG up to 3840x2160 at 30fps.
With NPU support for MobileNet V2 + SSDLite and YOLO7 object detection, the NMG-1242M5X-W gives developers a compact AI vision platform for object recognition, analytics, and smart camera integration. The 6-22mm motorized lens provides adjustable field-of-view control, making it useful when one camera must support both wider monitoring and closer inspection.
Key Features:
- 12MP global shutter IP camera module
- 6-22mm motorized lens for adjustable field-of-view control
- Sony 1/1.1” 12MP CMOS global shutter sensor
- Compact 42 x 42mm double-board design
- 64-bit Quad Core RISC-V processor with embedded Linux
- H.265, H.264, and MJPEG video encoding
- Up to 3840 x 2160 video at 30fps
- Integrated NPU for AI object detection
- MobileNet V2 + SSDLite and YOLO7 support
- Trigger input and Flash/IR output for synchronized imaging
- WDR, HLC, BLC, 2DNR, 3DNR, sharpness, brightness, and contrast controls
- Ideal for UAV, robotics, machine vision, surveillance, and intelligent traffic applications
Applications:
- UAV/drone zoom camera systems
- Robotics vision and object detection
- AI surveillance and smart monitoring
- Intelligent traffic camera systems
- Industrial inspection and automation
- Remote visual inspection
- Embedded edge AI camera platforms
- Smart city security systems
- Vehicle and equipment monitoring
- High-resolution inspection with adjustable viewing angle
| Brand | IPX |
| Model | NMG-1242M5X-W |
| Camera Type | 12MP IP Camera Module |
| Board Design | 42 x 42mm Double Board |
| Image Sensor | Sony CMOS Sensor, 1/1.1” 12MP |
| Shutter Type | Global Shutter |
| Lens | 6-22mm Motorized Lens |
| SoC | 64-bit Quad Core RISC-V |
| Operating System | Embedded Linux |
| Video Compression | H.265, H.264, MJPEG |
| Maximum Video Output | Up to 3840 x 2160 @ 30fps |
| NPU / AI Support | MobileNet V2 + SSDLite / YOLO7 Object Detection |
| Interfaces | Trigger In, Flash / IR Out |
| Video Processing | Sharpness, Brightness, Contrast, HLC, BLC, WDR, 2DNR, 3DNR |
| Dimensions | 42 x 42mm Camera Board |
| Lens Options | Custom lens options available by inquiry |
