IPX NMG-1242B60-W 12MP Global Shutter IP Camera Module, 42x42mm Double Board, 6mm Lens
The IPX NMG-1242B60-W is a compact 12MP global shutter IP camera module designed for applications that require higher subject detail, reduced motion distortion, and reliable embedded video performance. With its 6mm fixed lens, this model provides a narrower field of view than the 2.8mm and 4mm versions, making it well suited for targeted inspection, robotics vision, surveillance, intelligent traffic monitoring, and object detection at greater working distances.
Built with a Sony 1/1.1” 12MP global shutter CMOS sensor, the NMG-1242B60-W is designed for high-resolution capture of moving scenes and fast-changing environments. The onboard 64-bit Quad Core RISC-V SoC runs embedded Linux and supports H.265, H.264, and MJPEG video up to 3840x2160 at 30fps.
The integrated NPU supports MobileNet V2 + SSDLite and YOLO7 object detection, helping developers build intelligent embedded vision systems for AI detection, inspection, monitoring, and automation. Image enhancement features such as WDR, HLC, BLC, 2DNR, 3DNR, brightness, contrast, and sharpness control help optimize video quality in challenging lighting conditions.
Key Features:
- 12MP global shutter IP camera module
- Sony 1/1.1” CMOS sensor for high-resolution imaging
- 6mm fixed lens for improved subject detail and longer-view applications
- Compact 42 x 42mm double-board design
- Embedded Linux with 64-bit Quad Core RISC-V SoC
- H.265, H.264, and MJPEG video support
- Up to 3840 x 2160 video at 30fps
- Integrated NPU for AI object detection
- MobileNet V2 + SSDLite and YOLO7 model support
- Trigger input and Flash/IR output
- WDR, HLC, BLC, 2DNR, 3DNR, brightness, contrast, and sharpness adjustments
- Designed for machine vision, surveillance, UAV, robotics, and industrial imaging
Applications:
- Machine vision inspection
- Robotics object detection
- UAV and drone imaging
- Industrial automation cameras
- Intelligent traffic monitoring
- AI edge surveillance systems
- Smart factory vision
- Medical and scientific imaging
- Quality control and defect detection
- Security and perimeter monitoring
| Brand | IPX |
| Model | NMG-1242B60-W |
| Camera Type | 12MP IP Camera Module |
| Board Design | 42 x 42mm Double Board |
| Image Sensor | Sony CMOS Sensor, 1/1.1” 12MP |
| Shutter Type | Global Shutter |
| Lens | 6mm Fixed Lens |
| SoC | 64-bit Quad Core RISC-V |
| Operating System | Embedded Linux |
| Video Compression | H.265, H.264, MJPEG |
| Maximum Video Output | Up to 3840 x 2160 @ 30fps |
| NPU / AI Support | MobileNet V2 + SSDLite / YOLO7 Object Detection |
| Interfaces | Trigger In, Flash / IR Out |
| Video Processing | Sharpness, Brightness, Contrast, HLC, BLC, WDR, 2DNR, 3DNR |
| Dimensions | 42 x 42mm Camera Board |
| Lens Options | Custom lens options available by inquiry |
