IPX NMG-1242B40-W 12MP Global Shutter IP Camera Module, 42x42mm Double Board, 4mm Lens
The IPX NMG-1242B40-W is a high-resolution 12MP global shutter IP camera module engineered for embedded vision applications that require a balance between wide coverage and improved subject detail. Featuring a 4mm fixed lens, this 42x42mm double-board camera module is a strong choice for robotics, machine vision, UAV imaging, smart surveillance, intelligent traffic systems, and edge AI inspection platforms.
The NMG-1242B40-W uses a Sony 1/1.1” 12MP global shutter CMOS sensor, helping reduce motion artifacts when capturing moving objects, vehicles, conveyor lines, robotics targets, or UAV-based scenes. Its onboard 64-bit Quad Core RISC-V SoC with embedded Linux provides efficient video processing and supports H.265, H.264, and MJPEG output up to 3840x2160 at 30fps.
With integrated NPU acceleration for MobileNet V2 + SSDLite and YOLO7 object detection, the module can support smart detection workflows for embedded AI systems. Advanced image processing features including WDR, HLC, BLC, 2DNR, 3DNR, brightness, sharpness, and contrast control help maintain image quality in industrial, outdoor, and variable-light environments.
Key Features:
- 12MP Sony CMOS global shutter image sensor
- 4mm fixed lens for balanced field-of-view and object detail
- Compact 42 x 42mm double-board IP camera module
- Embedded Linux platform with 64-bit Quad Core RISC-V processor
- H.265, H.264, and MJPEG video encoding
- Up to 3840 x 2160 resolution at 30fps
- Built-in NPU for AI object detection
- Supports MobileNet V2 + SSDLite and YOLO7 detection models
- Trigger input and Flash/IR output for synchronized applications
- WDR, HLC, BLC, 2DNR, 3DNR, brightness, contrast, and sharpness control
- Ideal for robotics, traffic, surveillance, machine vision, and AI inspection systems
Applications:
- Robotics and autonomous machine vision
- UAV/drone inspection cameras
- AI object detection systems
- Industrial automation and inspection
- Smart surveillance camera systems
- Intelligent transportation and traffic monitoring
- Embedded vision product development
- Medical device imaging
- Factory quality control
- Security and access monitoring
| Brand | IPX |
| Model | NMG-1242B40-W |
| Camera Type | 12MP IP Camera Module |
| Board Design | 42 x 42mm Double Board |
| Image Sensor | Sony CMOS Sensor, 1/1.1” 12MP |
| Shutter Type | Global Shutter |
| Lens | 4mm Fixed Lens |
| SoC | 64-bit Quad Core RISC-V |
| Operating System | Embedded Linux |
| Video Compression | H.265, H.264, MJPEG |
| Maximum Video Output | Up to 3840 x 2160 @ 30fps |
| NPU / AI Support | MobileNet V2 + SSDLite / YOLO7 Object Detection |
| Interfaces | Trigger In, Flash / IR Out |
| Video Processing | Sharpness, Brightness, Contrast, HLC, BLC, WDR, 2DNR, 3DNR |
| Dimensions | 42 x 42mm Camera Board |
| Lens Options | Custom lens options available by inquiry |
