IPX NMG-1242B28-W 12MP Global Shutter IP Camera Module, 42x42mm Double Board, 2.8mm Lens

The IPX NMG-1242B28-W is a compact 12MP global shutter IP camera module designed for embedded vision systems that require high-resolution imaging, low-distortion capture, onboard video processing, and intelligent object detection. Built around a Sony 1/1.1” 12MP global shutter CMOS sensor, this 42x42mm double-board module is well suited for robotics, UAV/drone imaging, smart surveillance, AI edge vision, machine vision inspection, medical imaging, traffic monitoring, and industrial automation.

With a 2.8mm fixed lens, the NMG-1242B28-W is ideal for wider field-of-view applications where situational awareness and full-scene coverage are important. The onboard 64-bit Quad Core RISC-V processor runs embedded Linux and supports H.265, H.264, and MJPEG video up to 3840x2160 at 30fps. Integrated NPU support for MobileNet V2 + SSDLite and YOLO7 object detection enables AI-based detection workflows directly at the camera module level.

This module also includes advanced imaging controls such as WDR, HLC, BLC, 2D/3D noise reduction, sharpness, brightness, and contrast adjustment, making it a strong fit for changing lighting conditions, outdoor vision systems, and high-detail inspection environments.

Key Features:

• 12MP IP camera module with Sony 1/1.1” CMOS global shutter sensor
• 2.8mm fixed lens for wide field-of-view imaging
• Compact 42 x 42mm double-board camera module design
• 64-bit Quad Core RISC-V SoC with embedded Linux
• H.265, H.264, and MJPEG video compression
• Up to 3840 x 2160 video output at 30fps
• Integrated NPU for AI object detection
• Supports MobileNet V2 + SSDLite and YOLO7 detection models
• Trigger input and Flash/IR output for synchronized imaging
• WDR, HLC, BLC, 2DNR, 3DNR, sharpness, brightness, and contrast controls
• Designed for robotics, UAV, intelligent traffic, security, inspection, and embedded AI vision

Applications:

• UAV and drone vision systems
• Robotics navigation and object detection
• AI edge camera systems
• Industrial machine vision inspection
• Intelligent traffic monitoring
• Smart city surveillance
• Medical and laboratory imaging devices
• Automated quality control
• Embedded security systems
• Wide-area situational awareness cameras
