IPX NM-542M10X-W 5MP 42x42mm IP Camera Module with 5-50mm Motorized Lens, Single Board

The IPX NM-542M10X-W is a 5MP 42x42mm IP camera module with a 5-50mm motorized zoom lens for longer-range embedded imaging and intelligent network video applications. This model is ideal for OEM surveillance systems, remote monitoring, traffic applications, inspection platforms, robotics, parking analytics, and AI-enabled security devices where adjustable zoom and compact integration are important.

Using a 1/2.8" 5MP Sony CMOS sensor, a 64-bit Quad Core RISC-V SoC, and Embedded Linux, the NM-542M10X-W supports H.265, H.264, and MJPEG video up to 2592x1944 at 30fps. Its NPU supports MobileNet V2 + SSDLite and YOLOv7 object detection, while empty-space analytics for up to 12 spaces, optional number recognition, WDR, HLC/BLC, and 2D/3D noise reduction help support advanced smart camera deployments.

• 5MP 42x42mm IP camera module for OEM integration
• 5-50mm motorized zoom lens for long-range adjustable imaging
• 1/2.8" Sony CMOS image sensor
• 64-bit Quad Core RISC-V SoC with Embedded Linux
• H.265, H.264, and MJPEG video compression
• Up to 2592 x 1944 video output at 30fps
• NPU support for MobileNet V2 + SSDLite and YOLOv7 object detection
• Empty-space analytics for up to 12 spaces
• Optional number recognition software support
• Video processing controls for sharpness, brightness, contrast, HLC, BLC, WDR, 2DNR, and 3DNR
• Ideal for surveillance, traffic, remote monitoring, inspection, robotics, and AI vision applications
