IPX NM-532B60-W 5MP 6mm Lens Single Board IP Camera Module for AI Vision
IPX NM-532B60-W is a 5MP 6mm lens single board IP camera module with Sony CMOS imaging, Embedded Linux, H.265/H.264/MJPEG video, edge AI object detection, and empty space analytics for intelligent vision applications.
The IPX NM-532B60-W is a compact 5MP single board IP camera module built for embedded AI, industrial inspection, robotics, UAV, intelligent traffic, parking analytics, and surveillance applications. Designed on a 42 x 42mm camera board, this module is ideal for OEM systems requiring high-resolution video, onboard processing, and reliable IP camera performance.
Using a Sony 1/2.8" 5MP CMOS sensor and a 6mm lens, the NM-532B60-W is better suited for applications that need a narrower field of view with improved subject detail compared to wider lens options. It supports video output up to 2592 x 1944 at 30fps with H.265, H.264, and MJPEG compression.
The onboard 64-bit Quad Core RISC-V SoC runs Embedded Linux and supports intelligent edge processing through an integrated NPU. With MobileNet V2 + SSDLite and YOLO7 object detection, the module can support AI-based monitoring, object detection, smart parking, access control, number recognition, and automated vision systems.
Key Features:
- 5MP IPX single board IP camera module
- 6mm lens for tighter field-of-view applications
- Sony 1/2.8" 5MP CMOS sensor
- 64-bit Quad Core RISC-V SoC with Embedded Linux
- H.265, H.264, and MJPEG video compression
- High-resolution video up to 2592 x 1944 at 30fps
- Integrated NPU for edge AI vision processing
- Supports MobileNet V2 + SSDLite and YOLO7 object detection
- Empty space analytics for up to 12 monitored spaces
- Optional number recognition software support
- Image tuning features including sharpness, brightness, contrast, HLC, BLC, WDR, 2DNR, and 3DNR
- Compact 42 x 42mm board for embedded integration
Common Applications:
- AI object detection and embedded vision systems
- Parking analytics and smart space monitoring
- Number recognition and access control
- Robotics and autonomous platform imaging
- UAV and drone camera integration
- Industrial inspection and machine vision
- Traffic monitoring and smart city systems
- Surveillance systems requiring more focused image detail
| Brand | IPX |
| Model | NM-532B60-W |
| Camera Type | 5MP Single Board IP Camera Module |
| SoC | 64-bit Quad Core RISC-V |
| Operating System | Embedded Linux |
| Image Sensor | Sony CMOS Sensor |
| Sensor Size | 1/2.8" |
| Resolution | 5MP |
| Maximum Video Output | 2592 x 1944 at 30fps |
| Video Compression | H.265, H.264, MJPEG |
| Lens | 6mm Fixed Lens |
| NPU / AI Support | MobileNet V2 + SSDLite / YOLO7 for Object Detection |
| Key Feature | Empty Space Analytics, Up to 12 Spaces |
| Software Options | Number Recognition |
| Video Processing | Sharpness, Brightness, Contrast, HLC, BLC, WDR, 2DNR, 3DNR |
| Board Size | 42 x 42mm |
| Board Design | Single Board |
