IPX NM-532B40-W 5MP 4mm Lens Single Board IP Camera Module with Embedded AI
IPX NM-532B40-W is a compact 5MP 4mm lens single board IP camera module featuring a Sony CMOS sensor, Embedded Linux, H.265/H.264/MJPEG video, AI object detection, and empty space analytics for embedded vision applications.
The IPX NM-532B40-W is a 5MP single board IP camera module engineered for embedded AI vision, intelligent traffic, robotics, UAV, machine vision, parking analytics, and industrial surveillance systems. Its compact 42 x 42mm board design makes it ideal for OEM integration where space, processing efficiency, and image quality are critical.
Equipped with a Sony 1/2.8" 5MP CMOS sensor and a 4mm lens, the NM-532B40-W provides a balanced field of view for general-purpose monitoring, object detection, and recognition-based imaging applications. The camera supports H.265, H.264, and MJPEG video streams up to 2592 x 1944 at 30fps.
The built-in 64-bit Quad Core RISC-V processor with Embedded Linux allows the module to support advanced image processing and edge AI functions. With NPU support for MobileNet V2 + SSDLite and YOLO7, this IP camera board can be used for object detection, smart parking analytics, traffic monitoring, autonomous systems, and number recognition workflows.
Key Features:
- 5MP single board IP camera module from IPX
- 4mm lens for balanced coverage and recognition detail
- Sony 1/2.8" CMOS image sensor
- 64-bit Quad Core RISC-V SoC
- Embedded Linux operating platform
- H.265, H.264, and MJPEG video output
- 2592 x 1944 resolution at up to 30fps
- Integrated NPU for AI object detection
- Supports MobileNet V2 + SSDLite and YOLO7
- Empty space analytics for up to 12 parking or monitored spaces
- Optional number recognition software support
- Advanced image controls including WDR, HLC, BLC, 2DNR, and 3DNR
Applications:
- Parking management and empty space detection
- License plate or number recognition systems
- AI-enabled traffic monitoring
- Industrial automation and visual inspection
- Robotics and autonomous machine vision
- UAV and drone imaging systems
- Embedded security and surveillance platforms
- Smart city camera deployments
| Brand | IPX |
| Model | NM-532B40-W |
| Camera Type | 5MP Single Board IP Camera Module |
| SoC | 64-bit Quad Core RISC-V |
| Operating System | Embedded Linux |
| Image Sensor | Sony CMOS Sensor |
| Sensor Size | 1/2.8" |
| Resolution | 5MP |
| Maximum Video Output | 2592 x 1944 at 30fps |
| Video Compression | H.265, H.264, MJPEG |
| Lens | 4mm Fixed Lens |
| NPU / AI Support | MobileNet V2 + SSDLite / YOLO7 for Object Detection |
| Key Feature | Empty Space Analytics, Up to 12 Spaces |
| Software Options | Number Recognition |
| Video Processing | Sharpness, Brightness, Contrast, HLC, BLC, WDR, 2DNR, 3DNR |
| Board Size | 42 x 42mm |
| Board Design | Single Board |
