IPX NM-1242M10XH-W 12MP IP Camera Module, 42x42mm Double Board, 5-50mm Motorized Lens, Sony CMOS
The IPX NM-1242M10XH-W from Infinite Pixels is a 12MP IP camera module designed for applications that require long-range viewing flexibility, high-resolution video, and AI-powered edge analytics. With a 5-50mm motorized lens, Sony 1/2.3" 12MP CMOS sensor, embedded Linux, and compact 42 x 42mm double-board design, this module is ideal for long-range surveillance, intelligent traffic, perimeter monitoring, smart parking, industrial inspection, robotics, UAV/drone vision, and machine vision applications.
The 5-50mm motorized lens provides the most extended zoom range in this IPX NM-1242 12MP camera module group, allowing integrators to adjust from wider monitoring views to tighter long-range target observation. This makes the NM-1242M10XH-W a strong option for roadway monitoring, facility security, remote inspection, parking analytics, traffic systems, and AI object detection applications where flexible focal length control is required.
This Infinite Pixels 12MP IP camera module supports H.265, H.264, and MJPEG compression with video up to 3840 x 2880 at 20fps. The integrated 64-bit quad-core RISC-V SoC and embedded Linux platform provide a strong foundation for IP video processing, while onboard NPU support for MobileNet V2 + SSDLite and YOLO7 enables edge AI object detection. Additional features include empty space analytics for up to 12 spaces, optional number recognition, WDR, HLC, BLC, 2DNR, 3DNR, brightness, contrast, and sharpness controls.
Key Features:
- IPX / Infinite Pixels 12MP IP camera module
- Sony 1/2.3" 12MP CMOS image sensor
- 5-50mm motorized lens for long-range adjustable viewing
- Compact 42 x 42mm double-board embedded camera design
- Embedded Linux with 64-bit quad-core RISC-V SoC
- H.265, H.264, and MJPEG video compression
- Up to 3840 x 2880 video resolution at 20fps
- Integrated NPU with MobileNet V2 + SSDLite and YOLO7 object detection
- Empty space analytics support for up to 12 spaces
- Optional number recognition software support
- Advanced video processing with WDR, HLC, BLC, 2DNR, 3DNR, brightness, contrast, and sharpness
Applications:
- Long-range surveillance and perimeter security
- Intelligent traffic and roadway monitoring
- Smart parking and empty space analytics
- Industrial inspection and remote equipment monitoring
- Robotics and autonomous vision systems
- UAV/drone imaging and remote observation
- AI object detection and edge video analytics
- Machine vision and OEM embedded IP camera integration
| Brand | IPX / Infinite Pixels |
| Model | NM-1242M10XH-W |
| Camera Type | 12MP IP Camera Module |
| Board Design | Double Board |
| Dimensions | 42 x 42mm Camera Board |
| SoC | 64-bit Quad-Core RISC-V |
| Operating System | Embedded Linux |
| Image Sensor | Sony CMOS Sensor |
| Sensor Size | 1/2.3" |
| Resolution | 12MP |
| Video Resolution | Up to 3840 x 2880 @ 20fps |
| Series Class | 12MP IP Modules, 25fps Series |
| Video Compression | H.265, H.264, MJPEG |
| Lens | 5-50mm Motorized Lens |
| NPU / AI Support | MobileNet V2 + SSDLite / YOLO7 Object Detection |
| Key Analytics Feature | Empty Space Analytics, up to 12 spaces |
| Software Options | Number Recognition |
| Video Processing | Sharpness, Brightness, Contrast, HLC, BLC, WDR, 2DNR, 3DNR |
| Applications | Long-Range Surveillance, Intelligent Traffic, Smart Parking, Machine Vision, Robotics, Industrial Inspection, AI Vision |
