CIS DCC-4KNDI NDI® Compatible 4K POV Camera
The CIS DCC-4KZM is a high-performance 4K NDI® camera made in Japan and fully NDAA-compliant, engineered for professional IP video workflows that demand reliability, precision, and mobility. The addition of NDI® technology enhances system versatility by eliminating traditional SDI cabling—enabling a single Ethernet cable for simultaneous power, control, and video transmission. This streamlined setup makes the DCC-4KZM ideal for broadcast, live production, security, and industrial imaging environments.
Designed and manufactured in Japan, the DCC-4KZM delivers outstanding image quality through its 1/1.8" CMOS sensor and advanced Clairvu™ ISP for natural color reproduction and low-noise 4K imagery. An integrated 18x optical zoom lens with both Auto and Manual Focus ensures sharp images across various distances.
The DCC-4KZM supports full NDI®, Web API, and serial control, allowing seamless integration into NewTek Studio Monitor and other IP-based systems. With support for BT.2100 (HDR) and BT.2020 (WCG) color standards, along with PoE+ or 5V DC operation, this compact camera is ready for next-gen video workflows demanding flexibility, compliance, and premium Japanese engineering.
Features:
- 4K (3840x2160) 60p camera using 1/1.8“ CMOS image sensor
- Features state-of-the-art Clairvu™ ISP for high quality image processing and accurate color reproduction
- 18x integrated zoom lens with AF and MF controls
- Complies with full NDI® for true broadcast quality imagery
- Control via Web UI, Newtek Studio Monitor, Web API/REST API and serial connection
- Integrated AE and AWB
- Supports output in 4K and FHD resolutions
- BT.2100 (HDR) /BT.2020 (Wide Color Gamut) ready
- Video monitor output/Stereo audio line input
- PoE+ / DC 5V operation
Applications:
- Broadcast and live streaming production
- Government or defense installations requiring NDAA compliance
- Corporate and educational video conferencing
- Remote and mobile surveillance systems
- Industrial or machine vision monitoring
- Medical imaging and telemedicine
- House of worship and event production
- Control room and studio integration
*NDI® is a registered trademark of Vizrt Group
| Color/Mono | Color |
| Resolution | 3840 x 2160 |
| fps @ Max Resolution | 60 |
| Output Format | 4K UHDTV/1080p/1080i |
| Sensor Model Name | IMX334 |
| Shutter Type | Roling Shutter |
| Imager Size | 1/1.8 CMOS |
| Effective Pixels | 3864 x 2160 |
| Pixel Size (μm) | 2.0 x 2.0 |
| Power Consumption | 18W |
| Power Requirement | PoE+(IEEE802.3at), AC adpaptor:DC4.5V-5.05V |
| Min. Illumination | 0.7 lx |
| Sensitivity | F4.0 (2000lx) |
| Shutter Variable Range | 1/23.98s ～ 1/13600s |
| Interface | LAN(1000Base-T / PoE+) |
| Lens Mount | Zoom Lens Installed |
| Weight (g) | 500 |
| Dimensions (W) x (H) x (D)mm | 68 × 68.5 × 120.6 |
