CEI Machine Vision Camera Enclosure IP67 38mm Series Round
As a leading innovator in the Machine Vision Industry, CEI is proud to introduce our new line of Machine
Vision Camera Enclosures, Cables, and Accessories for demanding vision applications.
SKU
CEI Machine Vision Camera Enclosure IP67 38mm Series Round
CEI Machine Vision Camera Enclosure IP67 38mm Series Round
Features:
- CEI Integrated Connector Design (no cord grips)
- IP67 protection
- Universal design for popular 29mm camera models
- Excellent heat dissipation
- Enclosure tailored for specific Camera & Optics
- Adjustable Mount with 4 tapped holes included
- High quality (easy to replace) windows by Midwest Optical
- Lightweight low-profile design
- Type 2 anodizing
- Options: Mounts, Air Curtains, Windows & Filters, Cables
- Options: Custom Sizes, lengths, and focusing solutions.
- Competitive pricing
- Made in USA, Patent Pending
Applications:
- Machine Vision
- Industrial Inspection
- Quality Control
| Camera | 29mm square mount machine vision |
| Optics | Supports a wide range of C-Mount optics |
| Window | Midwest Optical 2mm AR coated Borofloat glass or Acrylic |
| Lens Covers | Available in 38mm, 44mm, 55mm, 60mm diameters Lengths in 10mm increments |
| Interface Connector | M12 X-Code Ethernet Female |
| Optional Interface Connector | M12 A-Code I/O Male, Cord Grip |
| Mounting | Qty. 2, M6 and Qty. 2 ¼-20 UNC tapped holes with 19.05mm (¾”) hole spacing Adjustable ring mount |
| Sealing | IP67 |
| Material | 6061 Aluminum |
| Coating | Type 2 anodized |
| Overall Length (L) | Varies, See Appendix “A” |
| Body Length (B) | 90 mm (incl. interface conn.) |
| Height / Width (C) | 44.5 mm round (body) |
| Mount Diameter | 69 mm |
| Window Diameter | 42 mm (48mm with 44mm cover) |
| Weight | 370 g (typical weight fully assembled W/ Camera) |
