Blackmagic Design URSA Mini Pro 12K Digital Film Camera
SKU
URSA Mini Pro 12K
Quick Overview
*Please note this product is subject to tariff fee*
Blackmagic Design URSA Mini Pro 12K: 12K resolution, Super 35 sensor, 14 stops dynamic range, Blackmagic RAW, 12G-SDI, dual media slots, high-speed frame rates, ND filters.The Blackmagic Design URSA Mini Pro 12K features a 12K Super 35 sensor with 14 stops of dynamic range, delivering exceptional image quality for high-end cinematic productions. It supports multiple resolutions up to 12,288 x 6,480 in Blackmagic Design RAW, with frame rates up to 160 fps in 8K and 4K modes. The camera offers user-interchangeable lens mounts (PL, EF, and F), built-in ND filters (2, 4, and 6 stops), and dual media slots for CFast 2.0 and SD UHS-II cards, plus USB-C support for external SSD recording. With timecode synchronization and metadata recording, it's designed for seamless integration into professional production workflows.
Connectivity options include 12G-SDI for video output, XLR audio inputs with phantom power, and LANC control for focus and recording. The camera's 4-inch capacitive touchscreen allows easy menu navigation, while DaVinci Resolve Studio ensures efficient post-production. Built for versatility, the URSA Mini Pro 12K is ideal for any professional set, offering high-speed performance, robust storage options, and a range of accessories for enhanced usability.
Features:
- 12K Super 35 Sensor (12,288 x 6,480)
- 14 Stops Dynamic Range
- Blackmagic RAW recording
- High-Speed Frame Rates: Up to 160 fps (4K/8K)
- Interchangeable Lens Mounts (PL, EF, F)
- Built-in ND Filters (2, 4, 6 stops IR)
- Dual Media Slots (CFast 2.0 & SD UHS-II)
- USB-C Recording (external SSD)
- 12G-SDI video output
- XLR Audio Inputs with phantom power
- 4-inch Touchscreen control
- Timecode Synchronization
- LANC Control (focus/record)
- DaVinci Resolve Studio included
Applications:
- Cinematic Filmmaking: High resolution and dynamic range for professional films.
- VFX & Post-Production: RAW recording for flexible editing.
- Slow Motion: Up to 160 fps for commercials and action scenes.
- Live Broadcasting: 12G-SDI for live events and multi-cam setups.
- Documentaries: Quick lens adjustments and ND filters for variable lighting.
- Sports Production: High frame rate support for fast action.
- Remote Filming: LANC control for gimbal or drone setups.
- Multi-Camera Shoots: Timecode sync for collaborative projects.
| Effective Sensor Size | 27.03mm x 14.25mm (Super35) |
| Lens Mount | PL mount included. Interchangeable with optional EF and F lens mounts. |
| Lens Control | 12pin broadcast connector for compatible lenses and electronic control via EF mount pins on optional EF lens mount. |
| Dynamic Range | 14 Stops |
| Shooting Resolutions | 12,288 x 6480 (12K DCI), 11,520 x 6480 (12K 16:9), 12,288 x 5112 (12K 2.4:1), 7680 x 6408 (12K anamorphic), 8192 x 4320 (8K DCI), 7680 x 4320 (8K 16:9), 8192 x 3408 (8K 2.4:1), 5120 x 4272 (8K anamorphic), 6144 x 3240 (6K Super16), 4096 x 2160 (4K Super16), 4096 x 2160 (4K DCI), 3840 x 2160 (4K 16:9), 4096 x 1704 (4K 2.4:1), 2560 x 2136 (4K anamorphic) |
| Frame Rates | 23.98, 24, 25, 29.97, 30, 50, 59.94, and 60 fps supported. |
| High Speed Frame Rates | 12K 17:9 full sensor up to 60 fps, 12K 2.4:1 up to 75 fps, 8K DCI full sensor up to 120 fps, 4K DCI full sensor up to 120 fps, 8K 2.4:1 and 4K 2.4:1 up to 160 fps, 6K Super 16 up to 120 fps, 4K Super 16 up to 240 fps |
| Built in ND Filters | Four position ND filter wheel with clear, 2-stop, 4-stop and 6-stop IR ND filters. |
| Focus | Focus button triggers auto focus when using compatible lenses with focus servo. Touch and hold on LCD determines focus region and triggers auto focus. |
| Microphone | Integrated stereo microphone. |
| Built in Speaker | 1 x mono speaker. |
| SD Video Standards | None |
| HD Video Standards | 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94, 1080i60 |
| Ultra HD Video Standards | 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60 |
| SDI Compliance | SMPTE 292M, SMPTE 424 Level B, SMPTE 2081-1, SMPTE 2082-1 |
| SDI Audio Sampling | 48 kHz and 24 bit |
| Media | 2 x CFast 2.0 card slots, 2 x SD UHS-II card slots, 1 x USB-C 3.1 Gen 2 expansion port (for external recording devices, media and power supply) |
| Alternative Media | 1 x 2.5” drive slot for 7mm and 9.5mm U.2 NVMe SSD or SATA SSD with optional URSA Mini Recorder. |
| Media Format | Can format media to ExFAT (Windows/Mac) or HFS+ (Mac) f ile systems |
| Codecs | Blackmagic RAW Constant Bitrate 5:1, Blackmagic RAW Constant Bitrate 8:1, Blackmagic RAW Constant Bitrate 12:1, Blackmagic RAW Constant Bitrate 18:1, Blackmagic RAW Constant Quality Q0, Blackmagic RAW Constant Quality Q1, Blackmagic RAW Constant Quality Q3, Blackmagic RAW Constant Quality Q5. |
| External Control | Blackmagic SDI Camera Control Protocol, iPad control, Bluetooth control, 1 x 2.5mm LANC for lens and record control. |
| Talkback | SDI Channels 15/16 and iPhone headset. |
| Live Tally Indicator | Tally on LCD, URSA Viewfinder and URSA Studio Viewfinder. |
| Storage Type | 2 x CFast 2.0 2 x SD UHS-II cards 1 x high speed USB-C expansion port for external media. |
| Storage Rates | 12K Full Sensor - 12,288 x 6480 at 24 frames per second. Blackmagic RAW 5:1 - 578 MB/s Blackmagic RAW 8:1 - 361 MB/s Blackmagic RAW 12:1 - 241 MB/s Blackmagic RAW 18:1 - 160 MB/s Blackmagic RAW Q0 - 289 to 1,156 MB/s Blackmagic RAW Q1 - 241 to 963 MB/ s Blackmagic RAW Q3 - 145 to 722 MB/ s Blackmagic RAW Q5 - 97 to 413 MB/s 8K Full Sensor - 8192 x 4320 at 24 frames per second. Blackmagic RAW 5:1 - 257 MB/s Blackmagic RAW 8:1 - 161 MB/s Blackmagic RAW 12:1 - 107 MB/s Blackmagic RAW 18:1 - 71 MB/s Blackmagic RAW Q0 - 257 to 642 MB/ s Blackmagic RAW Q1 - 214 to 428 MB/ s Blackmagic RAW Q3 - 107 to 321 MB/ s Blackmagic RAW Q5 - 81 to 257 MB/s 6K Super 16 - 6144 x 3240 at 24 frames per second. Blackmagic RAW 5:1 - 146 MB/s Blackmagic RAW 8:1 - 91 MB/s Blackmagic RAW 12:1 - 61 MB/s Blackmagic RAW 18:1 - 40 MB/s Blackmagic RAW Q0 - 73 to 291 MB/s Blackmagic RAW Q1 - 61 to 242 MB/s Blackmagic RAW Q3 - 37 to 182 MB/s Blackmagic RAW Q5 - 25 to 104 MB/s 4K Full Sensor - 4096 x 2160 at 24 frames per second. Blackmagic RAW 5:1 - 161 MB/s Blackmagic RAW 8:1 - 107 MB/s Blackmagic RAW 12:1 - 80 MB/s Blackmagic RAW 18:1 - 53 MB/s Blackmagic RAW Q0 - 161 to 268 MB/ s Blackmagic RAW Q1 - 107 to 214 MB/ s Blackmagic RAW Q3 - 81 to 179 MB/s Blackmagic RAW Q5 - 54 to 161 MB/s 4K Super 16 - 4096 x 2160 at 240 frames per second. |
| Recording Formats | Blackmagic RAW Q0, Q1, Q3, Q5, 5:1, 8:1, 12:1 and 18:1 at 12,288 x 6480, 11,520 x 6480, 12,288 x 5112, 7680 x 6408, 8192 x 4320, 7680 x 4320, 8192 x 3408, 5120 x 4272, 6144 x 3240, 4096 x 2160, 3840 x 2160, 4096 x 1704 and 2560 x 2136 stored as 12 bit non-linear with film, extended video, video or custom 3D LUT embedded in metadata. |
| Software Included | Blackmagic OS DaVinci Resolve Studio for Mac and Windows including activation key Blackmagic Camera Setup Blackmagic RAW Player Blackmagic RAW QuickLook Plugin Blackmagic RAW SDK Blackmagic RAW Speed Test |
| Operating Systems | Mac 13.0 Ventura, Mac 14.0 Sonoma or later. Windows 10 and 11. |
| Power Supply | 1 x External 12V power supply. 12 pin Molex connector for rear battery plate. |
| External Power Input | 1 x 4 pin XLR port for external power or battery use. 1 x 12 pin Molex connector on rear battery plate. Custom V-mount battery plate with D-tap +12V regulated output from camera. Power Rear camera mount compatible with industry standard V-mount or gold mount battery plates. |
| Optional Accessories | URSA Mini Pro PL, EF and F Mounts, URSA Mini Pro Shim Kit, URSA Mini Shoulder Kit including top handle and extender arm, URSA Viewfinder, URSA Studio Viewfinder, URSA Mini Recorder, URSA VLock Battery Plate, URSA Gold Battery Plate, URSA Mini Mic Mount, URSA Mini Top Handle, URSA Handgrip, Blackmagic Camera Fiber Converter. |
| Operating Temperature | 0° to 40°C (32° to 104°F) |
| Storage Temperature | -20° to 45°C (-4° to 113°F) |
| Relative Humidity | 0% to 90% non-condensing |
| What's Included | Blackmagic URSA Mini Pro 12K Body, Turret dust cap, PL lens mount, Power supply, DaVinci Resolve Studio activation key |
