Blackmagic Design PYXIS 6K EF Digital Film Camera
SKU
PYXIS 6K EF
Quick Overview
*Please note this product is subject to tariff fee*
The Blackmagic PYXIS 6K EF is a versatile digital film camera with a Full Frame HDR sensor, offering 6K resolution and up to 120 fps. Featuring a locking EF lens mount, dual native ISO, and 13 stops of dynamic range, it ensures superior image quality. With dual CFexpress slots and support for Blackmagic RAW recording, this camera is designed for high-end professional filmmaking.The Blackmagic Design PYXIS 6K EF Digital Film Camera is an advanced production tool, featuring a robust set of technical specifications for high-end filmmaking. The camera boasts a 36mm x 24mm Full Frame HDR sensor with a native resolution of 6048 x 4032, offering unparalleled image quality for cinematic production. It supports various resolutions including 6K (Open Gate, Anamorphic, and 16:9), 4K DCI, and Super 16 in both high frame rates (up to 120 fps) and low light conditions, thanks to its dual native ISO of 400 and 3200.
Equipped with a locking EF lens mount, the PYXIS 6K EF ensures compatibility with a wide range of Canon-compatible lenses, providing seamless focus and iris control. The camera features 13 stops of dynamic range, enabling detailed captures in both highlights and shadows. For connectivity, the camera offers a variety of ports, including 1 x 12G-SDI, mini XLR audio input, USB Type-C for external recording, and 1Gb Ethernet for remote control and file management.
With dual CFexpress Type B card slots and support for Blackmagic RAW and H.264 Proxy recording, the camera ensures fast, reliable media storage for high-resolution video. A customizable design with flexible mounting options makes it adaptable for various shooting setups. The camera's 4-inch touchscreen provides intuitive control and metadata support for efficient production workflows.
Features:
- Sensor: 36mm x 24mm Full Frame HDR
- Resolution: 6K (6048 x 4032) up to 120 fps
- Lens Mount: Locking EF
- Dynamic Range: 13 Stops
- Dual Native ISO: 400/3200
- Frame Rates: Up to 120 fps (1080p)
- Media: 2 x CFexpress Type B, USB-C
- Audio Inputs: Mini XLR, 3.5mm Stereo
- SDI Output: 12G-SDI (2160p60)
- Touchscreen: 4-inch, 1500 nits
- Timecode: Accurate, <1 frame drift/8 hours
- Power Supply: 12V DC, BP-U Series Battery
- Connectivity: 1Gb Ethernet, USB-C, Tri-Sync, Timecode
- Recording Codecs: Blackmagic RAW, H.264 Proxy
- Control: iPad, Bluetooth, USB PTP
- Metadata: Lens data, 3D LUT, Slate info
Applications:
- Cinematic Film Production
- Commercials & Advertising
- Documentaries
- Independent Filmmaking
- Live Event Recording
- High-Speed Action Shots
- Remote Filming & Broadcast
- Virtual Reality & 3D Production
- Post-Production Color Grading
- Broadcast Media & TV Shows
| Effective Sensor Size | 36mm x 24mm (Full Frame) |
| Lens Mount | Active, locking EF lens mount |
| Lens Control | Iris and focus on supported lenses |
| Dynamic Range | 13 Stops |
| Dual Native ISO | 400 and 3200 |
| Shooting Resolutions | 6048 x 4032 (Open Gate 3:2) up to 36 fps 4832 x 4032 (Anamorphic 6:5) up to 36 fps 6048 x 3408 (6K 16:9) up to 46 fps 6048 x 3200 (6K DCI 17:9) up to 48 fps 6048 x 2520 (6K 2.4:1) up to 60 fps 4096 x 3072 (Super 35 4:3) up to 50 fps 4096 x 2304 (4K 16:9) up to 60 fps 4096 x 2160 (4K DCI 17:9) up to 60 fps 2112 x 1184 (Super 16 16:9) up to 100 fps 1920 x 1080 (1080 HD 16:9) up to 120 fps |
| Frame Rates | Maximum sensor frame rate dependent on resolution and codec selected. Project frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 fps supported.Off-speed frame rates up to 60 fps in 6K 2.4:1 and 4K DCI 17:9, 100 fps in Super 16 16:9 and 120 fps in 1080HD. |
| Focus | Auto focus on compatible lenses |
| Iris Control | Manual iris with wheel and touchscreen |
| Screen | 4” 1920 x 1080, 1500 nits |
| Metadata Support | Automatically populated lens data from electronic EF lenses. Automatic recording of camera settings, motion sensor data plus slate data such as project, scene number, take and special notes. A 3D LUT can also be embedded in metadata of Blackmagic RAW files. |
| Controls | Touchscreen menus on 4 inch screen. Push buttons for other controls. 3 assignable shortcut keys. |
| Timecode Clock | < 1 frame drift every 8 hours |
| Total Video Inputs | None |
| Total Video Outputs | 1 x 12G-SDI up to 2160p60 |
| 1 x Viewfinder USB-C with power, data, video, and locking connector | |
| Analog Audio Inputs | 1 x mini XLR (mic with phantom power or line level, up to +14dBu) |
| 1 x 3.5mm Stereo Input | |
| Analog Audio Outputs | 1 x 3.5mm headphone jack |
| Reference Inputs | Tri-Sync/Black Burst and Timecode |
| Computer Interface | USB Type-C for external drive, PTP camera control, and software updates |
| Ethernet | 1 x 1Gb/s RJ‑45 (10/100/1000 BASE-T) |
| HD Video Standards | 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 |
| Ultra HD Video Standards | 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60 |
| SDI Compliance | SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081‑1, SMPTE 2081‑10, SMPTE 2082‑1, SMPTE 2082‑10 |
| SDI Audio Sampling | Television standard sample rate of 48 kHz and 24‑bit |
| Microphone | Integrated stereo microphone. |
| Built in Speaker | 1 x mono speaker. |
| Media | 2 x CFexpress Type B card slot, 1 x USB-C 3.1 Gen 1 expansion port for external media for Blackmagic RAW and H.264 Proxy Recording. |
| Media Format | Can format media to ExFAT (Windows/Mac) or HFS+ (Mac) file systems. |
| Codecs | Blackmagic RAW Constant Bitrate 3:1, Blackmagic RAW Constant Bitrate 5:1, Blackmagic RAW Constant Bitrate 8:1, Blackmagic RAW Constant Bitrate 12:1, Blackmagic RAW Constant Quality Q0, Blackmagic RAW Constant Quality Q1, Blackmagic RAW Constant Quality Q3, Blackmagic RAW Constant Quality Q5, H.264 Proxy in 1920 x 1080, 8-bit 4:2:0. |
| External Control | Blackmagic Zoom Demand and Blackmagic Focus Demand for controlling your camera and lens from tripod handles. iPad control, Bluetooth control, USB PTP camera control. External control of some camera settings, focus, iris and zoom with compatible lenses. Camera Control REST API over Ethernet for external control via HTTP when used with REST client applications such as Postman. |
| NTP | Network time protocol support allows you to sync the time on your camera, whenever connected to a network with any NTP server of your choice. |
| Web Media Manager | Using a browser connected over Ethernet, web media manager allows you to access, browse, download and delete files from any drive connected to the camera. |
| FTP | Download files from any drive attached to your camera using FTP. |
| SMB | File sharing using SMB. |
| Software Included | Blackmagic OS, DaVinci Resolve Studio for Mac and Windows including activation key, Blackmagic Camera Setup, Blackmagic RAW Player, Blackmagic RAW QuickLook Plugin, Blackmagic RAW SDK, Blackmagic RAW Speed Test. |
| Operating Systems | Mac 13.0 Ventura, Mac 14.0 Sonoma or later. Windows 10 and 11. |
| Power Supply | 1 x External 12V DC 60 W power supply. |
| External Power Input | 1 x 2‑pin locking connector. |
| Battery Type | BP-U series. |
| Power | 11-19.5V |
| Optional Accessories | Blackmagic URSA Cine Handle, Blackmagic URSA Cine EVF, Blackmagic PYXIS Rosette Plate |
| Operating Temperature | 0° to 40°C (32° to 104°F) |
| Storage Temperature | -20° to 45°C (-4° to 113°F) |
| Relative Humidity | 0% to 90% non-condensing |
| What's Included | Blackmagic PYXIS 6K EF, Lens turret dust cap, PYXIS Standard Plate, PYXIS SSD Plate, 60W power supply with locking connector and international adapters, Welcome booklet, DaVinci Resolve Studio activation key |
