Blackmagic Design BINTSSHU-THBOLT Intensity Shuttle Thunderbolt
Blackmagic Design BINTSSHU-THBOLT Intensity Shuttle Thunderbolt
SKU
Blackmagic Design BINTSSHU-THBOLT Intensity Shuttle Thunderbolt
Blackmagic Design Intensity Shuttle Thunderbolt (BINTSSHU-THBOLT)
Features:
- Uncompressed Data Transfer
- Up/Down Resolution Conversion
- HDMI Monitoring for Color Correction
- Bidirectional Thunderbolt Data Transfer
- HDMI and Analog Video and Audio Ports
- SD and HD Video In Full 10-Bit Quality
- 2 Ch. 24 Bit RCA / 8 Ch. HDMI Audio
- Inputs On 1 Side/Outputs On Other
- M.E. Software Solution Included
- Also Records Video Games
| Video Inputs | (1) HDMI (1) Component (1) Composite (1) S-video |
| Video Outputs | (1) HDMI (1) Component (1) Composite (1) S-video |
| Analog Audio Inputs | 2 Channel RCA HiFi audio in 24 bit |
| Analog Audio Outputs | 2 Channel RCA HiFi audio in 24 bit |
| HDMI Audio Input | 8 Channels |
| HDMI Audio Output | 8 Channels |
| Computer Interface | Thunderbolt |
| Resolutions Supported | HD: 1080i50, 1080i59.94, 1080i60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 720p50, 720p59.94 and 720p60 SD: 625i/50, 625p PAL and 525i/59.94, 525p NTSC, 480p |
| Sampling | HDMI Video: 4:2:2 HDMI Audio: Television standard sample rate of 48 kHz and 24 bit HDMI Color Precision: 4:2:2 HDMI Color Space: YUV 4:2:2 |
| Copy Protection | For legal reasons HDMI input is unable to capture from copy protected HDMI sources |
| Conversion | Colorspace Conversion: Hardware based, real time HD Down Conversion: Software based down conversion during video playback HD Up Conversion: Real time standard definition to 1080HD and 720HD during video capture |
| Effects | Real Time Effects: Avid Media Composer 6 internal effects in DNxHD, XDCAM and uncompressed Apple Final Cut Pro internal effects in DV, DVCPRO HD, ProRes and uncompressed on Intel Mac OS X Adobe Premiere Pro Mercury Playback Engine effects in DV, MJPEG, DVCPRO HD, DSLR, AVCHD, XDCAM, XDCAM HD and uncompressed |
| Firmware Upgrade | Firmware built into software driver. Loaded at system start, or via updater software |
| Compatibility | Requires Thunderbolt-equipped computer/storage device |
