AXIS P3905-R Mk III Dome Camera

Experience superior onboard surveillance with the AXIS P3905-R Mk III Dome Camera. Rugged, compliant with industry standards, and equipped with advanced features like Lightfinder and Forensic WDR, it ensures clarity in any lighting condition.

$0.00 Please call for pricing

SKU

P3905-R Mk III

Overview

Onboard Surveillance Excellence: AXIS P3905-R Mk III Dome Camera

Delve into the cutting-edge AXIS P3905-R Mk III Dome Camera, meticulously designed for onboard surveillance in challenging environments like trains and trams. Boasting a resilient 2 MP resolution, this industrial security camera excels in fluctuating light conditions with features like Lightfinder and Forensic WDR, ensuring clarity in dark and light areas. Its unique Traffic Light mode enhances scene understanding, distinguishing colors even in low light.

The camera, compliant with EN50155 and EN45545 standards, exhibits a rugged design with IK10, IP66, and IP67 ratings, capable of withstanding shocks, vibrations, and tough weather. It offers flexible installations with options like M12 or RJ45 connectors, and when paired with AXIS TP3826-E housing, it thrives on the exterior of vehicles.

With built-in cybersecurity features like Axis Edge Vault, unauthorized access is thwarted, providing a secure surveillance solution. The Axis Zipstream technology optimizes storage and bandwidth without compromising image quality, ensuring high-forensic usability and significant cost savings. This AXIS P3905-R Mk III Dome Camera is the epitome of reliability and performance, making it ideal for industrial and machine vision applications in the transportation sector.

Features:

2 MP Onboard Surveillance
Rugged Design (IK10, IP66, IP67)
Lightfinder and Forensic WDR
AXIS Zipstream Technology
Traffic Light Mode
EN50155 and EN45545 Compliance
Flexible Installation (M12 or RJ45 Connector)
Built-in Cybersecurity (Axis Edge Vault)

Applications:

Onboard Monitoring in Trains and Trams
Industrial Machine Vision
Transportation Industry Surveillance
Cost-Effective Security Solutions

Specifications

Models	AXIS P3905-R Mk III RJ45 AXIS P3905-R Mk III M12
Image Sensor	1/2.9” Progressive scan RGB CMOS Pixel size 2.8 µm
Lens	3.6 mm, F2.0 Horizontal field of view: 88° Vertical field of view: 47° Minimum focus distance: 0.3 m (1 ft) M12 mount, fixed iris See Optional accessories for exchangeable lenses
Minimum Illumination	Color: 0.04 lux at 30 IRE F2.0 Color: 0.13 lux at 50 IRE F2.0
Shutter Speed	With WDR: 1/19000 s to 1/5 s No WDR: 1/17000 s to 1/5 s
Camera Angle Adjustment	Pan ±30°, tilt 15 - 90°, rotation ±175°
Model	S6LM55
Memory	1024 MB RAM, 512 MB Flash
Video Compression	H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles Motion JPEG
Resolutions	16:9: 1920x1080 to 640X360 16:10: 1280x800 to 640x400 4:3: 1280x960 to 320x240
WDR	Forensic WDR: Up to 120 dB depending on scene
Frame Rate	H.264 and H.265: 25/30 fps (50/60 Hz) in all resolutions Motion JPEG: 15 fps (50/60 Hz) in all resolutions
Video Streaming	Up to 4 unique and configurable video streams Multiple, individually configurable streams in H.264, H.265 and Motion JPEG Axis Zipstream technology in H.264 and H.265 Controllable frame rate and bandwidth VBR/ABR/MBR H.264 and H.265 Video streaming indicator
Noise Reduction	Spatial filter (2D noise reduction) Temporal filter (3D noise reduction)
Image Settings	Compression, brightness, sharpness, contrast, white balance, Forensic WDR, exposure control, exposure zones, fine tuning of behavior at low light, rotation: 0°, 90°, 180°, 270° including Corridor Format, dynamic overlay, 32 individual polygonal privacy mask, mirroring of images Scene profiles: forensic, vivid, traffic overview
Image Processing	Axis Zipstream, Forensic WDR, Lightfinder
Pan/Tilt/Zoom	Digital PTZ, preset positions, guard tour, control queue
Network Protocols	IPv4, IPv6 USGv6, HTTP, HTTPSa, SSL/TLSa, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP®, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
Application Programming Interface	Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at axis.com One-click cloud connection ONVIF® Profile G, ONVIF® Profile M, ONVIF® Profile S, and ONVIF® Profile T, specification at onvif.org
Video Management Systems	Compatible with AXIS Companion, AXIS Camera Station, video management software from Axis’ Application Development Partners available at axis.com/vms
Onscreen Controls	Video streaming indicator Wide dynamic range Privacy masks
Event Conditions	Device status: above operating temperature, above or below operating temperature, below operating temperature, IP address removed, network lost, new IP address, storage failure, system ready, within operating temperature Edge storage: recording ongoing, storage disruption I/O: manual trigger, virtual input MQTT subscribe Scheduled and recurring: scheduled event Video: average bitrate degradation, live stream open, tampering
Event Actions	Guard tours Upload images or video clips: FTP, HTTP, HTTPS, SFTP, email and network share Notification: HTTP, HTTPS, TCP and email Overlay text Preset positions Record video: SD card and network share SNMP trap messages WDR mode MQTT publish
Built-in installation aids	Pixel counter
Applications	Included AXIS Video Motion Detection, active tampering alarmb Supported AXIS Fence Guard, AXIS Loitering Guard, AXIS Motion Guard Support for AXIS Camera Application Platform enabling installation of third-party applications
Product Markings	CE, ECE, KC, RCM, UL/cUL, UKCA, VCCI, WEEE
Supply Chain	TAA Compliant
Approvals	EMC EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, ECE R10 rev.06 (E approval), EN 50498, Australia/New Zealand: RCM AS/NZS CISPR 32 Class A Canada: ICES-3(A)/NMB-3(A) Japan: VCCI Class A, Korea: KS C 9835, KS C 9832 Class A, USA: FCC Part 15 Subpart B Class A Rolling stock: EN 50121-3-2, EN 50121-3-4, IEC 62236-4 Safety IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1, UN ECE R118 EN 45545-2, NFPA 130c Environment IEC/EN 60529 IP66, IEC/EN 60529 IP67, parts of Parts of NEMA 250 Type 4X (ingress of water and gasket test), IEC/EN 62262 IK10, IEC 60721-3-5 Class 5M3 (vibration and shock), IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-64, IEC 60068-2-78, IEC 60068–2–14 IEC/EN 61373 Category 1 Class B, EN 50155:2017 OT1/ST2 Network NIST SP500–267 Cybersecurity ETSI EN 303 645
Edge Security	Software: Signed firmware, brute force delay protection, digest authentication and OAuth 2.0 RFC6749 OpenID Authorization Code Flow for centralized ADFS account management, password protection, AES-XTS-Plain64 256bit SD card encryption Hardware: Axis Edge Vault cybersecurity platform Secure element (CC EAL 6+), system-on-chip security (TEE), Axis device ID, secure keystore, signed video, secure boot, encrypted filesystem (AES-XTS-Plain64 256bit)
Network Security	IEEE 802.1x (EAP-TLS, PEAP-MSCHAPv2), IEEE 802.1AE (MACsec PSK/EAP-TLS), IEEE 802.1AR, HTTPS/HSTS, TLS v1.2/v1.3, Network Time Security (NTS), X.509 Certificate PKI, host-based firewall
Casing	IP66/67-, Parts of NEMA 250 Type 4X- and IK10-rated aluminum and polycarbonate casing
Mounting	Inside vehicles and rolling stock
Power	Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 2 Typical 2.2 W, max 3.8 W
Connectors	RJ45: male, 10BASE-T/100BASE-TX M12: female, rugged, D-coded with rotatable coupling nut All connectors support PoE
Storage	Support for microSD/microSDHC/microSDXC card and encryption Support for recording to network-attached storage (NAS)
Operating Conditions	-30 °C to 55 °C (-22 °F to 131 °F) Maximum (intermittent): 70 °C (158 °F) Humidity: 10-100% RH (condensing)
Storage Conditions	-40 °C to 65 °C (-40 °F to 149 °F)
Approvals	EMC EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, RCM AS/NZS CISPR 32 Class A, KCC KN32 Class A, KN35, EN 50121-4, EN 50121-3-2, IEC 62236-4, ECE R10 rev.06 (E approval), EN 50498, EAC Safety IEC/EN/UL 62368-1, EN 45545, UN ECE R118, parts of NFPA 130d, IS 13252 Environment IEC/EN 61373 Category 1 Class B, IEC/EN 60529 IP66/67, NEMA 250 Type 4X, IEC/EN 62262 IK08, IEC 60721-3-5 Class 5M3 (vibration and shock), EN 50155:2017 Class OT2/ST2 (EN 50155:2007 Class TX), IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-64, IEC 60068-2-78 Network NIST SP500–267
Dimensions	Height: 50 mm (1.97 in) ø 110 mm (4.33 in)
Weight	241 g (0.53 lb)
Included Accessories	Camera, Installation guide, Windows® decoder 1-user license, lens tool
Optional Accessories	Lenses Lens M12 2.1 mm, F2.2: horizontal field of view 145° Lens M12 2.8 mm, F1.2: horizontal field of view 107° Lens M12 6 mm, F1.6: horizontal field of view 51° Lens M12 8 mm, F1.6: horizontal field of view 39° Other AXIS T94D01S Mount Bracket, AXIS T94D02S Curved Mount Bracket, Network coupler IP66, Network cable coupler indoor, TM3101 Pendant Wall Mount, AXIS TP3826-E housing, TP3827 Clear Dome Cover, TP3830 Top Black Cover
Video Management Software	AXIS Site Designer, AXIS Device Manager, product selector, accessory selector, lens calculator
Languages	English, German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese, Traditional Chinese
Warranty	5–year warranty

Downloads

AXIS P3905-R MK III Spec Sheet

(Size: 1.6 MB)
