Tru-Vu SRMH-13.3U-36 13.3" Sunlight Readable Monitors
*Please note this product is subject to tariff fee*
We design the SRMH-13.3U 1500 nit monitors to operate in nearly any environmental conditions. Whether in frigid conditions or blazing heat, these sunlight displays will survive and thrive. To clarify, these monitors will operate in temperatures down to -4°F (-20°C). They will also withstand brutal heat. Moreover, operating temperatures go up to 158°F (+70°C). The rugged steel enclosure assures these 13.3″high brightness displays will provide years of reliable imaging performance. Specifically, typical MTBF for these monitors is 50,000 hours.13″ MONITOR WITH EXTREME OPERATING TEMPERATURES
The SRMH-13.3U-36 are 13.3″ 1500 nit monitors. They feature at least 1500 nits brightness and a 16:9 aspect ratio. We design the SRMH-13.3U-36 monitors for use in direct sunlight. Consequently, they are also perfect for other high ambient-light conditions. They utilize state-of-the-art LED backlights. The models in this series produce at least 1,500 nits brightness. In contrast, this is over 3 to 5 times brighter than standard monitors. For example, standard monitors are only 200-300 nits brightness. Therefore, the result is amazingly bright screen. This will provide you with crystal-clear images, even with bright, direct sunlight on the face of the screen.
The SRMH-13.3U-36 13.3″ 1500 nit monitors are extremely rugged. For instance, we build them with true industrial-grade components. Furthermore, they receive our exclusive TRU-Tuff treatment. The TRU-Tuff process includes RTV silicone on all connections and critical components. Additionally, all wires are dressed, tie-wrapped and secured. Lastly, we apply ThreadLock to all screws. The steel enclosure will ensure maximum shock and vibration resistance for this rugged 1500 nit monitor.
Features:
- 1,500 nits Brightness – Clear, Sharp Images Even in Direct Bright Sunlight
- Full HD Resolution: 1920 x 1080 (1080p/60)
- Ambient Light Sensor Adjusts Screen Brightness Automatically
- Lockable On-Screen Display (OSD) Controls with Auto Re-Start After Power Loss
- TRU-Tuff Ensures Maximum Shock and Vibration Resistance
- 9-36VDC
- Can Be Customized to Meet Your Needs
Applications:
- Industrial
- Law Enforcement
- Aviation
- Marine
- Military
- Inspection
- Advertising
- Material Handling (cranes)
- Transportation applications
| LCD Panel | 13.3” AHVA LCD; LED Backlights |
| Resolution | 1920 x 1080 (1080P/60 Full HD) |
| Viewable Area | 11.55” (W) x 6.50” (H) (293.472 x 165.078 mm) |
| Pixel Pitch | 0.15285mm |
| Display Colors | 16.2 M |
| Aspect Ratio | 16:9 |
| Brightness | 1,500 nits |
| Contrast Ratio | 800:1 |
| Viewing Angle | 178° (H) x 178° (V) |
| Response Time | 25 msec Trf |
| Control | OSD (On-Screen Display) via Rear Panel Pushbuttons |
| Video Inputs | VGA, HDMI, Composite (BNC Loop-Thru) |
| Power Requirement | 9-36 VDC (2.5 mm Plug) |
| Power Consumption | 29 Watts |
| Enclosure | Painted Steel |
| Mounting | 100 x 100mm Rear VESA Mount Holes (M4 x 6mm Screws) |
| Operating Temperature | -4° to 158°F (-20° to 70° C) |
| Humidity | 5-90% RH |
| Shock | 50 G (20 msec, 1 / 2 sine) |
| Vibration | 1.5G RMS 10-200 HZ |
| Dimensions | 12.39” (W) x 8.05” (H) x 1.72” (D) (314.7 x 204.4 x 43.6 mm) |
| Weight | 4 lbs. (1.81 kg) |
| Warranty | 3 Years |
