IPX NM-1242M4X-W 12MP AI IP Camera Module with Sony CMOS Sensor, RISC-V SoC & 2.7-13.5mm Motorized Lens

The IPX NM-1242M4X-W from Infinite Pixels is a compact 12MP AI IP camera module featuring a 2.7-13.5mm motorized lens for flexible wide-to-medium scene coverage. Designed for OEM embedded vision, smart parking, intelligent traffic, surveillance, robotics, UAV/drone imaging, machine vision, and industrial monitoring, this module combines high-resolution IP video with onboard edge AI processing in a compact 42mm x 42mm double-board design.

At the core of the NM-1242M4X-W is a Sony 1/2.3" 12MP CMOS sensor, a 64-bit quad-core RISC-V SoC, embedded Linux, and an integrated NPU for AI object detection. The camera supports H.265, H.264, and MJPEG video compression with up to 3840 x 2880 resolution at 20 fps, giving integrators a strong balance of image detail, IP video flexibility, and compact embedded system design.

The 2.7-13.5mm motorized lens makes this model especially useful when a system needs wide coverage during some use cases and tighter framing in others. It is a strong fit for smart parking areas, entry points, loading zones, traffic corridors, compact surveillance systems, autonomous platforms, and adjustable OEM camera installations. The module also supports empty space analytics for up to 12 spaces, optional number recognition, and advanced image processing such as WDR, HLC, BLC, 2DNR, and 3DNR.

Key Features:

• IPX / Infinite Pixels 12MP AI IP camera module
• Sony 1/2.3" 12MP CMOS image sensor
• 64-bit quad-core RISC-V SoC running embedded Linux
• Integrated NPU for AI object detection at the edge
• Supports MobileNet V2 + SSDLite and YOLO7
• H.265, H.264, and MJPEG video compression
• Up to 3840 x 2880 resolution at 20 fps
• 2.7-13.5mm motorized lens for wide-to-medium adjustable coverage
• Compact 42mm x 42mm double-board camera module
• Empty space analytics for up to 12 spaces
• Optional number recognition software support
• Video processing: sharpness, brightness, contrast, HLC, BLC, WDR, 2DNR, and 3DNR

Common Applications:

• Smart parking and space monitoring
• Number recognition and vehicle monitoring
• Entry point and access surveillance
• Intelligent traffic systems
• Robotics and autonomous systems
• UAV and drone camera payloads
• Industrial inspection and automation
• OEM embedded AI camera systems
