IPX NM-1242M10X-W 12MP AI IP Camera Module with Sony CMOS Sensor, RISC-V SoC & 5-50mm Motorized Lens
The IPX NM-1242M10X-W from Infinite Pixels is a compact 12MP AI IP camera module designed for longer-range adjustable imaging applications. Featuring a 5-50mm motorized lens, Sony 1/2.3" 12MP CMOS sensor, 64-bit quad-core RISC-V SoC, embedded Linux, and integrated NPU processing, this module is built for smart surveillance, intelligent traffic, parking analytics, perimeter monitoring, UAV/drone observation, robotics, industrial inspection, and OEM embedded vision systems.
The NM-1242M10X-W supports H.265, H.264, and MJPEG video compression with up to 3840 x 2880 resolution at 20 fps. Its onboard NPU supports object detection using MobileNet V2 + SSDLite and YOLO7, helping integrators deploy edge AI camera systems for vehicle monitoring, target detection, empty space analytics, number recognition workflows, and smart scene analysis.
The 5-50mm motorized lens gives this model the longest adjustable lens range in the listed series, making it a strong fit for applications that require tighter framing, greater viewing flexibility, or longer-distance scene coverage than shorter lens models. It is well suited for perimeter security, traffic chokepoints, parking lot observation, loading dock monitoring, industrial process monitoring, and remote surveillance systems where the camera angle or field of view may need to be adjusted after installation.
Key Features:
- IPX / Infinite Pixels 12MP AI IP camera module
- Sony 1/2.3" 12MP CMOS image sensor
- 64-bit quad-core RISC-V SoC with embedded Linux
- Integrated NPU for edge AI object detection
- Supports MobileNet V2 + SSDLite and YOLO7 object detection
- H.265, H.264, and MJPEG video compression
- Up to 3840 x 2880 video resolution at 20 fps
- 5-50mm motorized lens for longer-range adjustable viewing
- Empty space analytics for up to 12 spaces
- Optional number recognition software support
- Compact 42mm x 42mm double-board camera module
- Video processing: sharpness, brightness, contrast, HLC, BLC, WDR, 2DNR, and 3DNR
Common Applications:
- Longer-range surveillance and perimeter monitoring
- Parking lot analytics and vehicle monitoring
- Traffic chokepoint and roadway observation
- Number recognition camera systems
- UAV and drone observation payloads
- Robotics and autonomous monitoring
- Industrial inspection and process monitoring
- OEM embedded AI IP camera systems
| Brand | IPX / Infinite Pixels |
| Model | NM-1242M10X-W |
| Camera Type | AI IP Camera Module |
| Image Sensor | Sony CMOS Sensor |
| Sensor Size | 1/2.3" |
| Resolution | 12MP |
| Maximum Video Resolution | 3840 x 2880 |
| Maximum Frame Rate | 20 fps |
| Shutter Type | Rolling Shutter |
| SoC | 64-bit Quad-Core RISC-V |
| Operating System | Embedded Linux |
| Video Compression | H.265, H.264, MJPEG |
| NPU / AI Processing | Integrated NPU for Object Detection |
| AI Model Support | MobileNet V2 + SSDLite / YOLO7 |
| Analytics | Empty Space Analytics, up to 12 Spaces |
| Software Options | Number Recognition |
| Video Processing | Sharpness, Brightness, Contrast, HLC, BLC, WDR, 2DNR, 3DNR |
| Lens | 5-50mm Motorized Lens |
| Board Size | 42mm x 42mm |
| Board Design | Double Board |
| Form Factor | Board-Level Camera Module |
